Product Details
Place of Origin: China
Brand Name: Puyang Zhongshi Group
Certification: API,ISO,QHSE
Model Number: 4 1/2"~36"
Payment & Shipping Terms
Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: Wooden Box
Delivery Time: depends on quantity
Payment Terms: T/T, MoneyGram
Product: |
7" BTC Thread Float Collar And Float Shoe |
Processing: |
Forging |
Feature: |
PDC Drillable |
Material: |
P-110, K55, J55, N80,L80 |
Thread: |
BTC |
Reverse Pressure: |
35 Mpa |
Product: |
7" BTC Thread Float Collar And Float Shoe |
Processing: |
Forging |
Feature: |
PDC Drillable |
Material: |
P-110, K55, J55, N80,L80 |
Thread: |
BTC |
Reverse Pressure: |
35 Mpa |
Float Shoe and Float Collar for Well Cementing
The round nose guides the casing away from ledges and obstructions in the well bores as the casing is lowered. A build-in check valve provides buoyancy to the casing string also prevents cement from re-entering the casing after it is displaced.
Qualified concreting procedure.
The valve is capable of withstanding long periods of circulation.
Either PDC or rock bit drillable.
.Float Shoe and Float Collar for Well Cementing
Specification(in) | O.D.(mm) | I.D. (mm) | Total length(mm) | Min.Dia. (mm) | Conn Type | Affordable strength of back-pressure(Mpa) | |
Float Shoe | 5 | 140.3 | 110 | 495 | 50 | 5 BCSG | 35 |
5 1/2 | 153.67 | 122 | 514 | 55 | 5 1/2 BCSG | 35 | |
7 | 194.46 | 162.5 | 533 | 77 | 7 BCSG | 35 | |
9 5/8 | 269.88 | 225 | 550 | 77 | 9 5/8 BCSG | 35 | |
13 3/8 | 339.7 | 319 | 550 | 77 | 133/8 BCSG | 35 | |
20 | 534 | 475 | 652 | 77 | 20 BCSG | 35 | |
Float Collar | 5 | 141.3 | 110 | 500 | 50 | 5 BCSG | 35 |
5 1/2 | 153.67 | 112 | 530 | 55 | 5 1/2BCSG | 35 | |
7 | 194.46 | 162.5 | 586 | 77 | 7 BCSG | 35 | |
9 5/8 | 270 | 225 | 720 | 77 | 9 5/8 BCSG | 35 | |
13 3/8 | 365 | 319 | 720 | 77 | 133/8 BCSG | 35 | |
20 | 533.4 | 475 | 720 | 77 | 20 BCSG | 35 |
