Product Details
Place of Origin: China
Brand Name: Zhongshi
Certification: API 5CT, API 11AX ISO, QHSE
Model Number: 1.05"-4 1/2"
Payment & Shipping Terms
Minimum Order Quantity: 1 metric ton
Price: Negotiable
Packaging Details: Be bundled by steel strap
Payment Terms: T/T, L/C
OD: |
4 1/2" |
Threads: |
EU, NU And Plain End |
Type: |
OCTG |
Steel Grade: |
J55 K55 N80 L80 P110 Etc. |
Material: |
Alloy Steel |
Packing: |
Packed By Steel Strap Or As Request |
OD: |
4 1/2" |
Threads: |
EU, NU And Plain End |
Type: |
OCTG |
Steel Grade: |
J55 K55 N80 L80 P110 Etc. |
Material: |
Alloy Steel |
Packing: |
Packed By Steel Strap Or As Request |
API Well Casing and Screen Pipes continuous slot wedge wire Tubing 2-7/8"(PERFO) & WWS,200 MS
Characteristics:
This type of well screen is also known as V wire wrapped well screens, wedge wire screens cylinder (due to the outline pipe forms), V Wire Screen, reversed slot screen water filter, stainless steel slot tube (due to ss material is the most popular) or pipe base well screen.
Technical specification:
| Specification | Weight code | Outside diameter (mm) | Wall thickness (mm) | Inner diameter (mm) | Calculated weight | ||||
| NUE(with thread and coupling) | EUE(with thread and coupling) | Plain end (kg/m) | Changed weight due to end process(kg) | ||||||
| Plain(with thread and coupling) | External upset threaded and coupled | ||||||||
| standard coupling | special coupling | ||||||||
| 1.9 | 2.75 | 2.9 | 48.26 | 3.68 | 40.9 | 4.05 | 0.27 | 0.91 | - |
| 2-3/8 | 4.6 | 4.7 | 60.32 | 4.83 | 50.66 | 6.61 | 0.73 | 1.81 | 1.34 |
| 2-7/8 | 6.4 | 6.5 | 73.02 | 5.51 | 62 | 9.17 | 1.45 | 2.54 | 1.71 |
| 2-7/8 | 8.6 | 8.7 | 73.02 | 7.82 | 57.38 | 12.57 | 1.18 | 2.27 | 1.43 |
| 3-1/2 | 9.2 | 9.3 | 88.9 | 6.45 | 76 | 13.12 | 2.27 | 4.17 | 2.45 |
| 3-1/2 | 12.7 | 12.95 | 88.9 | 9.52 | 69.86 | 18.64 | 1.81 | 3.72 | 2 |
| 4 | 10.7 | 11 | 101.6 | 6.65 | 88.3 | 15.57 | - | 4.81 | - |
| 4-1/2 | 12.6 | 12.75 | 114.3 | 6.88 | 100.54 | 18.23 | 2.72 | - | - |
