Nickel Carbide Fuel Pump Plunger And Barrel API 11B Standard

Name: Nickel Carbide Fuel Pump Plunger And Barrel API 11B Standard
Brand: Puyang Zhongshi Group Co., Ltd.
SKU: Sucker rod pump
Price: 155.00 USD
Availability: InStock

Product Details

Place of Origin: China

Brand Name: Zhongshi

Certification: API，ISO，QHSE

Model Number: Sucker rod pump

Payment & Shipping Terms

Minimum Order Quantity: 1 set

Price: Negotiable

Packaging Details: Standard exported packing

Delivery Time: 10~15 workdays

Payment Terms: T/T, D/P, D/A, L/C, Western Union

Supply Ability: 1000 Sets per Month

Get Best Price

Product Details

Product Description

Highlight:
                                                                                                                                                                                                                                                Carbide Fuel Pump Plunger And Barrel, API 11B Fuel Pump Plunger And Barrel, API 11B plunger barrel


Standard:	API 11 AX	Application:	Main Pump Parts
Coating:	Nickel Carbide	Material:	AISI1045 Steel
Warranty:	12 Months	Hardness:	55HRA-62HRA

Standard:	API 11 AX
Application:	Main Pump Parts
Coating:	Nickel Carbide
Material:	AISI1045 Steel
Warranty:	12 Months
Hardness:	55HRA-62HRA

Nickel Carbide Fuel Pump Plunger And Barrel API 11B Standard

Nickel Carbide Barrel Oilfield Pump Parts API 11B

Nickel Carbide Barrel Description

The pump barrel assembly of the tubing pump connected on the tubing string,and with its down to the bottom of the well.Plunger assembly connected on the sucker rod string and with it down to the pump barrel position in the well,then with it do up and down reciprocating motion, so as to realize the production process.
Pump barrel: plain carbon steel plating (A1), ordinary carbon steel carbonitriding (B1), ordinary carbon steel carburizing (B2), low alloy steel nitride (B5). The most common of these components and the final types of assembled pumps are covered by American Petroleum Institute (API)

specification API 11AX.

Technical Specifications:

Pump model	Nominal Pump Bore (in)	Plunger Length(ft)	Max.O.D.(mm)	Rod size(in)	Tubing(in)	Pump Constant (m3/d)
20-112RHBC	1.12	4~6	46.7	3/4	2 3/8	0.92
20-112RHBM			44.7
20-125RHBC	1.25		47.5	3/4	2 3/8	1.14
20-125RHBM			44.7
25-150RHBC	1.5		59.5	3/4	2 7/8	1.64
25-150RHBM			55.6
25-175RHBC	1.75		59.5	3/4	2 7/8	2.24
25-175RHBM			55.6
30-225RHBC	2.25		72.1	3/4	3 1/2	3.69
30-225RHBM			71.7

Nickel Carbide Fuel Pump Plunger And Barrel API 11B Standard 0
