Product Details:
Payment & Shipping Terms:
|
Machine Type: | Petroleum Machinery | Application: | Petroleum Production |
---|---|---|---|
Color: | Required | Usage: | Oil Field |
Type: | Sucker Rod,Rod Pump | Standard: | API |
High Light: | oil sucker pump,subsurface sucker rod pump |
Thin Wall Barrel API ISO QHSE Certification Reliable Mud Anchor Rod Pump
Product description
In combination with the size of the tubing, the RW pump of the same pump diameter can be smaller than the RH pump tubing. For example, the minimum tubing size required for an RH rod pump with a pump diameter of 44.5 mm is 2-7/8", while RW The minimum tubing required for a rod pump requires only 2-3/8".
Technical parameter list
Specification | Pump diameter (in) | Plunger length (ft) | Stroke length (ft) | Tubing size EUE(in) | Sucker rod size |
20-125RWBC | Ø31.75 | 0.3-8.0 | 1.2-9.0 | 2-3/8” |
CYJ16 CYJ19 |
20-150RWBC | Ø38.10 | 2-3/8” | |||
25-200RWBC | Ø50.80 | 2-7/8” | |||
30-250RWBC | Ø63.50 | 3-1/2” |
