Straight Vane Bow Spring Centralizer 4 1/2 - 13 3/8”Lightweight Thermal Plastic Material

Product Details

Place of Origin: China

Brand Name: Puyang Zhongshi Group

Certification: API,ISO,QHSE

Model Number: 4 1/2"~36"

Payment & Shipping Terms

Minimum Order Quantity: 1

Price: Negotiable

Packaging Details: Wooden Box

Delivery Time: depends on quantity

Payment Terms: T/T, MoneyGram

Get Best Price
Highlight:

spiral glider centralizer

,

solid body centralizer

Material:
Thermal Plastic
Color:
Black Or White
Size:
4 1/2~13 3/8”
Feature:
Without Steel Ring
Blade:
4~12
Advantage:
Light Weight
Material:
Thermal Plastic
Color:
Black Or White
Size:
4 1/2~13 3/8”
Feature:
Without Steel Ring
Blade:
4~12
Advantage:
Light Weight
Straight Vane Bow Spring Centralizer 4 1/2 - 13 3/8”Lightweight Thermal Plastic Material

Thermal Plastic Straight Vane Centralizer Without Steel Ring



With the emergence of more and more special well conditions, such as large displacement Wells, other types of centralizer in the process of lowering the difficulty gradually reflected


Features
  • The resin cyclone centralizer has a clockwise spiral flow channel, which can change the single one-dimensional axial flow displacement mode.
  • High impact and yield strength, so that it is not easy to deformation and damage in use..
  • Low density, small weight, easy to carry and use, and has a high resistance to high temperature.

Specification

Specification Inner Diameter
(mm)
Height
(mm)
Outer Diameter (mm)
13 3/8"×17 1/2" 345 250/300 438
13-3/8" ×16” 345 250/300 400
10 3/4"×16" 276 250/300 305
9 5/8"×12 1/4" 247 250/300 305
7 5/8"×9 1/2" 196 250/300 235
7"× 9 7/8" 181 250/300 245
7"× 8 1/2" 181 250 210
7"× 9 1/2" 181 250 235
5 1/2"× 8 1/2" 141 250 210
4 1/2"×6" 117 250 148
