Product Details
Place of Origin: China
Brand Name: Puyang Zhongshi Group
Certification: API,ISO,QHSE
Model Number: 4 1/2"~36"
Payment & Shipping Terms
Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: Wooden Box
Delivery Time: depends on quantity
Payment Terms: T/T, MoneyGram
Type: |
Solid Rigid Type |
Vane: |
Straight |
Roller: |
Depends |
Material: |
65Mn,steel 20 |
Color: |
Red Color |
Feature: |
Reduce Downloading Resistance |
Type: |
Solid Rigid Type |
Vane: |
Straight |
Roller: |
Depends |
Material: |
65Mn,steel 20 |
Color: |
Red Color |
Feature: |
Reduce Downloading Resistance |
Solid Rigid Straight Vanes Roller Centralizer for Casing Drilling with API
The top wire casing rigid roller centralizer consists of a rigid body, on which machined five spiral blades. There are three or four modified alloy steel, fully heat treated rollers fixed on every spiral blades. The assembly is shown as following fig. Because of rigid body and rolling friction between the rollers and inside of well or casing, the capability of the top wire casing rigid roller centralizer is better than others of all. Recommend to use the tool in deviated holes and horizontal holes.
| Casing centralizer | Min Hole | I.D. | O.D. | OAL |
| (mm/inch) | (mm/inch) | (mm/inch) | (mm/inch) | (mm/inch) |
| 139.7(5-1/2) | 215.9(8-1/2) | 143(5-5/8) | 211(8-5/16) | 260(10-1/4) |
| 177.8(7) | 215.9(8-1/2) | 181(7-1/8) | 213.4(8-13/32) | 260(10-1/4) |
| 244.5(9-5/8) | 311.15(12-1/4) | 247.5(9-11/16) | 305.4(12-1/64) | 260(10-1/4) |
| 339.7(13-3/8) | 406.4(16) | 344(13-35/64) | 402(15-53/64) | 260(10-1/4) |
