Product Details:
Payment & Shipping Terms:
|
Standard: | API 11 AX | Usage: | Oil |
---|---|---|---|
Structure: | Piston Pump,Single-stage Pump | Material: | Alloy Steel |
Warranty: | One Year | Feature: | High Efficiency |
High Light: | sand control screens,ball valve seat |
Heavy Weight Pump Barrel Assembly With High Efficiency One Year Warranty
Product Description
The pump barrel assembly of the tubing pump connected on the tubing string,and with its down to the bottom of the well.Plunger assembly connected on the sucker rod string and with it down to the pump barrel position in the well,then with it do up and down reciprocating motion, so as to realize the production process.
Features
1.Rod pump can be pulled out from the well directly.
2.Well inspection and workover is convenient.
3.Reduce the cost of pumping test.
4.Suitable for deeper well.
Technical Specifications:
Specification | Nominal Pump Bore (in) | Plunger Length(ft) | Max.O.D.(mm) | Rod(in) | Tubing(in) | Pump Constant (m3/d) |
20-112RHBC | 1.12 | 4~6 | 46.7 | 3/4 | 2 3/8 | 0.92 |
20-112RHBM | 44.7 | |||||
20-125RHBC | 1.25 | 47.5 | 3/4 | 2 3/8 | 1.14 | |
20-125RHBM | 44.7 | |||||
25-150RHBC | 1.5 | 59.5 | 3/4 | 2 7/8 | 1.64 | |
25-150RHBM | 55.6 | |||||
25-175RHBC | 1.75 | 59.5 | 3/4 | 2 7/8 | 2.24 | |
25-175RHBM | 55.6 | |||||
30-225RHBC | 2.25 | 72.1 | 3/4 | 3 1/2 | 3.69 | |
30-225RHBM | 71.7 |
