Product Details:
Payment & Shipping Terms:
|
| Usage: | Oil Production | Material: | Alloy Steel |
|---|---|---|---|
| Plunger Length: | Spray Metal P21-175 | Pump Barrel: | Brass B13-225 |
| Ball Seat: | Tungsten CarbideV11-225 | Warranty: | One Year |
| High Light: | sand control screens,ball valve seat |
||
Sucker Rod Oilfield Pump Parts Brass Pump Barrel B13-225 Spray Metal Plunger
Product Description
The valve ball and seat is a important part of the oil field mining pump, it's using directly decides the service life of rod pump. According to the corrosion characteristics of oil, oil Wells can provide different material
Feature :
1. High compressive strength, hardness and resistance against wear, and the ability to withstand shock and also impact
2. Usage: making of valves of sock rod pumps
3. Other usage : Flow meters, ball screws and linear bearings, gauging and in ball pens
4. Grade: YG6,YN6, YTR
5. HRA: 89.5-91.0
6. Magnetic : Can be done according to customer’s requirements
7. Size : 1/8’’(Φ3.175mm)-3-3/4’’(Φ95.25mm)
API valve Ball and valve Seat Size
| Dimensional Symbol | V11-106 | V11-125 | V11-150 | V11-175 | V11-200 | V11-225 | V11-250 | V11-375 |
| Ball-D(mm) |
15.88 (0.625in) |
19.05 (0.75in) |
23.83 (0.938in) |
28.58 (1.125in) |
31.75 (1.25in) |
34.93 (1.375in) |
42.88 (1.688in) |
57.15 (2.25in) |
| Seat-ID(mm) |
11.68 (0.46in) |
13.97 (0.55in) |
17.02 (0.67in) |
20.96 (0.825in) |
24.38 (0.96in) |
26.92 (1.06in) |
33.27 (1.31in) |
43.18 (1.7in) |
| Seat-OD(mm) |
20.14 (0.793in) |
23.32 (0.918in) |
29.67 (1.168in) |
35.26 (1.388in) |
37.54 (1.478in) |
43.69 (1.72in) |
51.05 (2.01in) |
78.03 (3.072in) |
| Seat-H(mm) |
0.500 (12.70in) |
0.500 (12.70in) |
0.500 (12.70in) |
0.500 (12.70in) |
0.500 (12.70in) |
0.500 (12.70in) |
0.500 (12.70in) |
0.750 (19.05in) |
| API No. | V11-106 | V11-125 | V11-150 | V11-175 | V11-200 | V11-225 | V11-250 | V11-375 |
| Seat Size | 1-1/16" | 1-1/4" | 1-1/2" | 1-3/4" | 2" | 2-1/4" | 2-3/4" | 3-3/4" |
| Ball Size | 5/8" | 3/4" | 15/16" | 1-1/8" | 1-1/4" | 1-3/8" |
1-11/16" |
2-1/4" |
