Product Details:
Payment & Shipping Terms:
|
Type: | Non-rotating | Material: | Rubber |
---|---|---|---|
Color: | As Required | Core Inside: | Aluminum Inside |
Temperature: | -30℃ To 150℃ | Working Pressure: | ≥15MP |
High Light: | 114'' Top Plug Cementing,127'' Top Plug Cementing,114'' Oilfield Cementing Tools |
API Oilfield Downhole Tools Cementing Top Plug
Cementing Plugs from high-performance special elastomers and core materials. These Cementing Plugs are specially designed with a positive wiping action to ensure that the casing is clean.
API Oilfield Downhole Tools Cementing Top Plug Features
These plugs are completely PDC drillable.
Temperature with Aluminum core is up to 200 degree Fahrenheit.
Plug can be ordered for higher operating temperature and operation in either synthetic or mud fluids
The top plug has a solid body that provides positive indication of contact with the landing collar and bottom plug through an increase in pump pressure.
Inch size | MM O.D(mm) | Labial ministry diameter(mm) | Main body diameter(mm) | Bore Dia (mm) |
Length (mm) |
|||
Rubber | Polyurethane | Rubber | Polyurethane | Rubber | Polyurethane | |||
101 | 101~104 | 96~99 | 94~97 | 89~92 | 77~80 | 72~75 | ≥40 | 100~190 |
114 | 114~116 | 109~111 | 108~110 | 102~105 | 80~83 | 75~78 | ||
127 | 127~130 | 122~125 | 120~123 | 115~118 | 90~93 | 87~90 | ≥50 | 120~210 |
140 | 140~145 | 135~140 | 130~ 135 | 125~130 | 100~103 | 97~100 | ||
178 | 178~183 | 173~175 | 168~173 | 163~168 | 130~135 | 125~130 | ≥70 | 150~240 |
194 | 194~201 | 189~196 | 182~189 | 177~184 | 145~150 | 140~145 | ||
219 | 219~223 | 214~218 | 210~214 | 205~209 | 168~173 | 163~168 | 180~260 | |
244 | 244~249 | 239~243 | 234~239 | 229~234 | 192~197 | 187~192 | ||
273 | 273~279 | 268~273 | 262~268 | 257~263 | 210~214 | 205~209 | 220~300 | |
298 | 298~305 | 293~297 | 286~293 | 281~288 | 236~243 | 231~238 | ||
340 | 340~348 | 335~343 | 326~334 | 321~329 | 264~272 | 259~267 | 260~350 | |
508 | 508~519 | 503~514 | 490~501 | 485~496 | 424~435 | 419~430 | ≥100 | 360~450 |
