API float shoes and collars 13 3/8" Cement Float Equipment

Name: API float shoes and collars 13 3/8" Cement Float Equipment
Brand: Puyang Zhongshi Group Co., Ltd.
SKU: 4 1/2"~36"
Price: 275.00 USD
Availability: InStock

Product Details

Place of Origin: China

Brand Name: Puyang Zhongshi Group

Certification: API,ISO,QHSE

Model Number: 4 1/2"~36"

Payment & Shipping Terms

Minimum Order Quantity: 1

Price: Negotiable

Packaging Details: Wooden Box

Delivery Time: depends on quantity

Payment Terms: T/T, MoneyGram

Get Best Price

Product Details

Product Description

Highlight:
                                                                                                                                                                                                                                                13 3/8" Cement Float Equipment, API Float Shoes And Collars, 13 3/8" float shoes and collars


Product:	13 3/8" API Float Collars And Float Shoes	Fill-in:	Cement Or Alumium
Usage:	Drilling Equipment	Material:	P-110, K55, J55, N80,L80 Or As Required
Thread:	STC/BTC/LTC Or As Required	Reverse Pressure:	35 Mpa

Product:	13 3/8" API Float Collars And Float Shoes
Fill-in:	Cement Or Alumium
Usage:	Drilling Equipment
Material:	P-110, K55, J55, N80,L80 Or As Required
Thread:	STC/BTC/LTC Or As Required
Reverse Pressure:	35 Mpa

API float shoes and collars 13 3/8" Cement Float Equipment

13 3/8" API Float Collars and Float Shoes Description

The float shoe contains a backpressure valve that prevents fluids from entering the casing while the pipe is lowered into the hole and prevents cement from flowing back into the casing after placement, while enabling circulation down through the casing.

Float collars are placed one to three joints above the guide shoe or float shoe. They provide a seat for the cement plugs, the bottom plug pumped ahead of the cement and the top plug behind the full volume of slurry. Once seated, the top plug shuts off fluid flow and prevents over-displacement of the cement. The space between the float shoe and the float collar provides a containment area to entrap the likely-contaminated fluids from the wiping action of the top cementing plug, securing the contaminated fluid away from the shoe where a strong cement bond is of primary importance. Float collars include a backpressure valve and serve basically the same function as the float shoe.

Features

Reduce strain on the derrick while guiding casing past ledges and slough zones in the hole;
Provide a landing point for bottom and top cementing plugs (pumped ahead of and behind the slurry as part of cementing operations);
Provide a backpressure valve to prevent cement from flowing back into the inner diameter of the casing after the cement has turned the corner into the annulus and the top plug has been bumped.

Specification

Specification(in)		O.D.(mm)	I.D. (mm)	Total length(mm)	Min.Dia. (mm)	Conn Type	Affordable strength of back-pressure(Mpa)
Float Shoe	5	140.3	110	495	50	5 BCSG	35
	5 1/2	153.67	122	514	55	5 1/2 BCSG	35
	7	194.46	162.5	533	77	7 BCSG	35
	9 5/8	269.88	225	550	77	9 5/8 BCSG	35
	13 3/8	339.7	319	550	77	133/8 BCSG	35
	20	534	475	652	77	20 BCSG	35
Float Collar	5	141.3	110	500	50	5 BCSG	35
	5 1/2	153.67	112	530	55	5 1/2BCSG	35
	7	194.46	162.5	586	77	7 BCSG	35
	9 5/8	270	225	720	77	9 5/8 BCSG	35
	13 3/8	365	319	720	77	133/8 BCSG	35
	20	533.4	475	720	77	20 BCSG	35

API float shoes and collars 13 3/8" Cement Float Equipment 0
