Product Details:
Payment & Shipping Terms:
|
Parts Name: | Pump Plunger | Material: | AISI1045 Steel |
---|---|---|---|
Plunger Length: | <= 6m | Coating: | Spray Metal, Chrome Plated |
Coating Thickness: | Min. 0.008" | Application: | Main Parts Of Rod Pumps |
High Light: | AISI1045 Oilfield Pump Parts,Plungers Oilfield Pump Parts,AISI1045 pump plungers |
Big Size Corrosion Resistant Pump Plungers Oilfield Pump Parts
Rod pump plungers description
Plungers of rod pump is the necessary oilfield pump parts, which is used in sucker rod pumps and tubing pumps.
Plunger: 1045 steel spraying (B1), 1045 steel spraying (B2), 1045 steel chrome plating (A1), 1045 steel double chrome plating (A2).
Features
1.Mechanical properties, surface finish and dimensional accuracy is higher than the standard requirements.
2.Corrosion resistant,
3.Coating process: spray metal coating and chrome plated
Technical parameters
size(mm) | OD mm (-0.013-0mm) | Length m (+/-6.35mm) | Note |
Ø28 | Ø26.99 | not above 6.6m | PL<2.1,Straightness measurement value is less than0.03mm/ft;PL≥2.1m,Straightness measurement value is less than0.18mm/ft |
Ø32 | Ø31.75 | ||
Ø38 | Ø38.10 | ||
Ø44 | Ø44.45 | ||
Ø50 | Ø50.80 | ||
Ø57 | Ø57.15 | ||
Ø63 | Ø63.50 | ||
Ø70 | Ø69.85 | ||
Ø95 | Ø95.25 |
Spray Metal processing for plungers
