API10D Slip On With Set Screw Stop Collar Casing

Name: API10D Slip On With Set Screw Stop Collar Casing
Brand: Puyang Zhongshi Group Co., Ltd.
SKU: 4 1/2"~36"
Price: 105.00 USD
Availability: InStock

Product Details

Place of Origin: China

Brand Name: Puyang Zhongshi Group

Certification: API,ISO,QHSE

Model Number: 4 1/2"~36"

Payment & Shipping Terms

Minimum Order Quantity: 1

Price: Negotiable

Packaging Details: Wooden Box

Delivery Time: depends on quantity

Payment Terms: T/T, MoneyGram

Get Best Price

Product Details

Product Description

Highlight:
                                                                                                                                                                                                                API10D Stop Collar Casing, 10 3/ 4'' Stop Collar Casing, API10D stop collar drilling


Product:	API10D Slip-on With Set Screw Stop Collar	Size:	Different Sizes Are Available
Installation:	Slip-on Type	Material:	65Mn,steel 20
Feature:	Used In Deviated Wells And Horizontal Wells

Product:	API10D Slip-on With Set Screw Stop Collar
Size:	Different Sizes Are Available
Installation:	Slip-on Type
Material:	65Mn,steel 20
Feature:	Used In Deviated Wells And Horizontal Wells

API10D Slip On With Set Screw Stop Collar Casing

API10D Slip-on with Set Screw stop Collar

Stop collars use set screws for increased holding force. The hinged design is for applications on upset tubing. These stop collars are available in slip-on for tight clearances and hinged for semi-tight clearances.

API10D Slip-on with Set Screw stop Collar Features

Stop collars use set screws for increased holding force.
For both tubing and casing applications.
Tapered pin hold the bows and hinges in the collars
The whole casing centralizer is made without any rivet and no welding.
The whole casing centralizer is composed of 3 parts, the spring, the hinges and tapered pin.
High-quality, super-strengthen spring-steel bows and especialy designed collar hinges
The non-weld design eliminates any weak spots.

API10D Slip-on with Set Screw stop Collar Specification

Specification (Inch)	ID (mm)	OD (mm)	Holding Force (KN)
13 3/ 8”	338	350	40
10 3/ 4”	272	284	40
9 5/ 8”	245	257	40
8 1/ 8”	206	218	40
7 5/ 8”	193	285	30
7”	177	189	30
5 1/ 2”	139	151	30
5”	126	138	24
4 1/ 2”	114	126	24

API10D Slip On With Set Screw Stop Collar Casing 0
