Heavy Wall Cup Bottom Seating Sucker Rod Pump

Product Details

Place of Origin: China

Brand Name: Zhongshi

Certification: API, ISO, QHSE

Model Number: Sucker rod pump

Payment & Shipping Terms

Minimum Order Quantity: 1 set

Price: Negotiable

Packaging Details: Standard exported packing

Delivery Time: 10~15 workdays

Payment Terms: L/C, D/P, T/T, Western Union, D/A

Supply Ability: 1000 SETS/MONTH

Get Best Price
High Light:

Bottom Seating Sucker Rod Pump

,

AISI1045 Sucker Rod Pump

,

AISI1045 Oilfield Sucker Rods

Type Of Seating Assembly:
Cup
Location Of Seating Assembly:
Bottom
Barrel Material:
Carbon Steel AISI1045
Barrel Coating:
Chrome Plated
Plunger Coating:
Spray Metal
API Certificate:
API 11AX-0061
Type Of Seating Assembly:
Cup
Location Of Seating Assembly:
Bottom
Barrel Material:
Carbon Steel AISI1045
Barrel Coating:
Chrome Plated
Plunger Coating:
Spray Metal
API Certificate:
API 11AX-0061
Heavy Wall Cup Bottom Seating Sucker Rod Pump

Heavy Wall Cup Bottom Seating Sucker Rod Pump



Cup Bottom Seating Sucker Rod Pump Description



Cup bottom seating sucker rod pump is the cup seating assembly rod pump. Sucker rod pump is equipped with a seating nipple(there are two seating nipples in API-RHBM-AC) , seating nipple connection on the tubing string, down to the bottom of the well with the tubing string. Plunger assembly is connected on the rod string and together with the whole pump down to support joint position, pump is fixed within the support joint by external force, plunger assembly is together with the sucker rod string up and down reciprocating movement to achieve pumping work. Don't need to put out of the tubing string when the sucker rod pump is mantained, only through rod string together put out of the whole pump, operation is simple.



Technical parameter list:



Specification Pump diameter (in) Barrel length (ft) Plunger length (ft) Stroke length (ft) Extension length (ft) Tubing size EUE(in)
15-106RHBC Ø26.99         1.9"
20-125RHAC Ø31.75 2.1-10 0.3-8.0 1.2-9.0 0.3-0.9 2-3/8”
20-125RHBC
25-150RHAC Ø38.10 2-7/8”
25-150RHBC Ø38.10
25-175RHAC Ø44.45
25-175RHBC
30-225RHBC Ø57.15 3-1/2"
30-225RHAC



Features


1. Cup type seating assembly.
2. The material of cup seating assembly is composite, so the cup seating sucker rod pump is suitable for oil well with lower temperature
3. The pump barrel is heavy walled, so the pump is endurable.
