RHBM Stationary Mechanical Bottom Anchor Oil Sucker Pump

RHBM Stationary Mechanical Bottom Anchor Oil Sucker Pump
RHBM Stationary Mechanical Bottom Anchor Oil Sucker Pump

Large Image :  RHBM Stationary Mechanical Bottom Anchor Oil Sucker Pump

Product Details:

Place of Origin: China
Brand Name: Zhongshi
Certification: API, ISO, QHSE
Model Number: Sucker rod pump

Payment & Shipping Terms:

Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: Standard exported packing
Delivery Time: 10~15 workdays
Payment Terms: L/C, D/P, T/T, Western Union, D/A
Supply Ability: 1000 SETS/MONTH
Detailed Product Description
Type Seating Assembly: Mechanical Location Of Seating Assembly: Bottom
Pump Barrel: Heavy Walled And Thin Walled Certificate: API 11AX-0061
Barrel Material: 45# Steel Plunger Material: 45# Steel
High Light:

RHBM Oil Sucker Pump


Stationary Oil Sucker Pump


RHBM Bottom Anchor Pump

RHBM Stationary Mechanical Bottom Anchor Suker Rod Pump


Mechanical Anchor Sucker Rod Pump Description


 Mechanical anchor sucker rod pump is stronger than the cup anchor rod pump. This kind of rod pump is also equipped with a support joint, support joint connected on the tubing string, and it is together with the tubing string down to the bottom. Plunger assembly is connected on the rod string and together with the whole pump down to support joint position, pump is fixed within the support joint by external force, plunger assembly is together with the sucker rod string up and down reciprocating movement to achieve pumping work.When inspection and maintenance pump,it need not to put out of the tubing string, only through rod string together put out of the whole pump, operation is simple. Mechanical anchor rod pump can withstand high oil well temperature.


Technical parameter list:


Specification Pump diameter (in) Barrel length (ft) Plunger length (ft) Stroke length (ft) Extension length (ft) Tubing size EUE(in)
15-106RHBM Ø26.99 2.1-10.4 0.3-8.0 1.2-9.0 0.3-0.9 1.9"
20-125RHAM Ø31.75 2-3/8”
25-150RHAM Ø38.1 2-7/8”
25-175RHBM Ø44.45
30-225RHAM Ø57.15 3 1/2"



1. suitable for corrosion and small amount of sand and gas, deep Wells, such as complex well conditions, the use of safe, stable performance and wide application.
2. Endurable rod pump with heavy wall barrel

4. Mechanical rod pump are running inside the tubing with the support joint ,it is suitable for high temperature of deep well


RHBM Stationary Mechanical Bottom Anchor Oil Sucker Pump 0
