Thin Walled Mechanical Top Seating Sucker Rod Pump

Name: Thin Walled Mechanical Top Seating Sucker Rod Pump
Brand: Puyang Zhongshi Group Co., Ltd.
SKU: Sucker rod pump
Price: 19,525.00 USD
Availability: InStock

Product Details

Place of Origin: China

Brand Name: Zhongshi

Certification: API, ISO, QHSE

Model Number: Sucker rod pump

Payment & Shipping Terms

Minimum Order Quantity: 1 set

Price: Negotiable

Packaging Details: Standard exported packing

Delivery Time: 10~15 workdays

Payment Terms: L/C, D/P, T/T, Western Union, D/A

Supply Ability: 1000 SETS/MONTH

Get Best Price

Product Details

Product Description

Highlight:
                                                                                                                                                                                                                                                AISI 1045 Sucker Rod Pump, API 11AX-0061 Sucker Rod Pump, AISI 1045 sinker bar rod pump


Type Seating Assembly:	Mechanical	Location Of Seating Assembly:	Top
Pump Barrel:	Thin Walled	Plunger Coating:	Spray Metal
Barrel Material:	AISI 1045 Steel	Certificate No.:	API 11AX-0061

Type Seating Assembly:	Mechanical
Location Of Seating Assembly:	Top
Pump Barrel:	Thin Walled
Plunger Coating:	Spray Metal
Barrel Material:	AISI 1045 Steel
Certificate No.:	API 11AX-0061

Thin Walled Mechanical Top Seating Sucker Rod Pump

Thin Walled Mechanical Top Seating Suker Rod Pump

Mechanical Top Seating Sucker Rod Pump Description

Mechanical top seating sucker rod pump is a kind of thin wall rod pump. This kind of rod pump is also equipped with a support joint, support joint connected on the tubing string, and it is together with the tubing string down to the bottom. Plunger assembly is connected on the rod string and together with the whole pump down to support joint position, pump is fixed within the support joint by external force, plunger assembly is together with the sucker rod string up and down reciprocating movement to achieve pumping work.When inspection and maintenance pump,it need not to put out of the tubing string, only through rod string together put out of the whole pump, operation is simple. Mechanical seating pump can be suitable for higher oil well temperature, but the thin wall pump is not endurable as heavy wall pump.

Technical parameter list:

Specification	Pump diameter (in)	Barrel length (ft)	Plunger length (ft)	Stroke length (ft)	Extension length (ft)	Tubing size EUE(in)
20-125RWAM	Ø31.75	2.1-10	0.3-8.0	1.2-9.0	/	2-3/8”
20-125RWBM
20-150RWAM	Ø38.1					2-7/8”
20-150RWBM
25-200RWAM	Ø50.80
25-200RWBM
30-250RWAM	Ø63.50					3 1/2"
30-250RWBM

Features

.
1. Thin wall barrel mechanical seating rod pump

2. Mechanical rod pump are running inside the tubing with the support joint ,it is suitable for high temperature of deep well

Thin Walled Mechanical Top Seating Sucker Rod Pump 0
