Heavy Wall And Thin Wall Cup Anchor Sucker Rod Pump

Name: Heavy Wall And Thin Wall Cup Anchor Sucker Rod Pump
Brand: Puyang Zhongshi Group Co., Ltd.
SKU: Sucker rod pump
Price: 19,525.00 USD
Availability: InStock

Product Details

Place of Origin: China

Brand Name: Zhongshi

Certification: API, ISO, QHSE

Model Number: Sucker rod pump

Payment & Shipping Terms

Minimum Order Quantity: 1 set

Price: Negotiable

Packaging Details: Standard exported packing

Delivery Time: 10~15 workdays

Payment Terms: L/C, D/P, T/T, Western Union, D/A

Supply Ability: 1000 SETS/MONTH

Get Best Price

Product Details

Product Description

Highlight:
                                                                                                                                                                                                                                                Anchor Sucker Rod Pump, Heavy Wall Sucker Rod Pump, 26.99'' gas anchor rod pump


Type Of Seating Assembly:	Cup	Location Of Seating Assembly:	Top And Bottom
Barrel Type:	Heavy Wall And Thin Wall	Barrel Material:	Carbon Steel, Alloy Steel
Plunger Coating:	Spray Metal	Warranty Term:	One Year

Type Of Seating Assembly:	Cup
Location Of Seating Assembly:	Top And Bottom
Barrel Type:	Heavy Wall And Thin Wall
Barrel Material:	Carbon Steel, Alloy Steel
Plunger Coating:	Spray Metal
Warranty Term:	One Year

Heavy Wall And Thin Wall Cup Anchor Sucker Rod Pump

Heavy Wall And Thin Wall Cup Anchor Sucker Rod Pump

Cup Seating Sucker Rod Pump Description

Cup anchor sucker rod pump is the cup seating assembly rod pump. Top cup anchor and bottom cup anchor. Cup seating rod pump is equipped with a seating nipple, seating nipple connection on the tubing string, down to the bottom of the well with the tubing string. Plunger assembly is connected on the rod string and together with the whole pump down to support joint position, pump is fixed within the support joint by external force, plunger assembly is together with the sucker rod string up and down reciprocating movement to achieve pumping work. If the cup top anchor sucker rod pump appeared quality problem ,it need not to put out of the tubing string, only through rod string together put out of the whole pump, operation is simple. But the cup seating assembly is not suitable the high temperature oil well enviroment.

Technical parameter list:

Heavy wall series parameters

Specification	Pump diameter (in)	Barrel length (ft)	Plunger length (ft)	Stroke length (ft)	Extension length (ft)	Tubing size EUE(in)
15-106RHBC	Ø26.99					1.9"
20-125RHAC	Ø31.75	2.1-10	0.3-8.0	1.2-9.0	0.3-0.9	2-3/8”
20-125RHBC	Ø31.75					2-3/8”
25-150RHAC	Ø38.10					2-7/8”
25-150RHBC	Ø38.10
25-175RHAC	Ø44.45
25-175RHBC	Ø44.45
30-225RHBC	Ø57.15					3-1/2"
30-225RHAC	Ø57.15					3-1/2"

Features

1. Cup top anchor and cup bottom anchor
2. Poor resistance to high temperature
3. The pump barrel is divided into heavy wall and thin wall

Heavy Wall And Thin Wall Cup Anchor Sucker Rod Pump 0
