Product Details:
Payment & Shipping Terms:
|
Product: | Sucker Rod Pump With Nickel-plated Barrel | Application: | Petroleum Production |
---|---|---|---|
Color: | Required | Machine Type: | Oil Extraction Equipment |
Material: | Carbon Steel,Stainless Steel | ||
High Light: | 1.5" Bore Hole Water Pump,1.25" Bore Hole Water Pump,1.25" down hole pump |
Sucker Rod Pump with Nickel-plated Barrel
Product description
The rod pump is connected to sucker rod after being assemblied on the surface then it is pulled down to the well bottom through the tubing.
The workover process of tubing pump is: firstly the barrel being connected to the tubing is directly run into the well at desired depth and then the plunger is run into the barrel with the sucker rod.
.
Technical parameter list
Specification | Pump diameter (in) | Barrel length (ft) | Plunger length (ft) | Stroke length (ft) | Extension length (ft) | Tubing size EUE(in) | Sucker rod size |
20-125RWAC | Ø1.25” | +2.1-10.4 | 0.3-8.0 | 1.2-9.0 | / | 2-3/8” |
CYJ16 CYJ19 |
20-150RWAC | Ø1.50” | 2-3/8” | |||||
25-200RWAC | Ø2.00” | 2-7/8” | |||||
30-250RWAC | Ø2.50” | 3-1/2 |
Material and Surface Treatment of Sucker Rod Pump
Parts | Material, Surface treatment | Special requirements |
Barrel | Carbon Steel, Chrome plate, nickel-phosphorous plate, carbonitriding, carburized | Brass barrel |
Plunger | Carbon steel, nickel spray, chrome plate | Double chrome plate |
Ball & Seat | Stainless steel, Tungsten carbide, Titanium carbide | Nickel carbide |
Cage | Alloy steel | Hard-lined |
