Product Details
Place of Origin: China
Brand Name: Zhongshi
Certification: API, ISO, QHSE
Model Number: Sucker rod pump
Payment & Shipping Terms
Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: Standard exported packing
Delivery Time: 10~15 workdays
Payment Terms: L/C, D/P, T/T, Western Union, D/A
Supply Ability: 1000 SETS/MONTH
Product: |
API High Pressure Sucker Rod Pump With Nickel-plated Barrel |
Standard: |
API 11AX |
Size Of Bore: |
26.9-69.9mm |
Application: |
Oil,petroleum Production |
Length: |
As Request |
Plunger Length (ft): |
2-24 |
Product: |
API High Pressure Sucker Rod Pump With Nickel-plated Barrel |
Standard: |
API 11AX |
Size Of Bore: |
26.9-69.9mm |
Application: |
Oil,petroleum Production |
Length: |
As Request |
Plunger Length (ft): |
2-24 |
API High Pressure Sucker Rod Pump with Nickel-plated Barrel
Product Description
The rod pump is connected to sucker rod after being assemblied on the surface then it is pulled down to the well bottom through the tubing.
The workover process of tubing pump is: firstly the barrel being connected to the tubing is directly run into the well at desired depth and then the plunger is run into the barrel with the sucker rod.
Technical Specifications:
| Specification | Nominal Bore mm(in) |
Plunger Length m(ft) |
Max. O.D. mm |
Rod in |
Tubing in | Pump Constant m3/d | Stroke m |
|
| 20-125 TH | 32 (1.25) | 1.2-1.8(4-6) | 73 | 3/4 | 2-3/8 | 1.14 | ≤8.0 | |
| 25-125 TH | 32 (1.25) | 88.9 | 3/4 | 2-7/8 | 1.14 | |||
| 20-150 TH | 38 (1.50) | 73 | 3/4 (5/8) | 2-3/8 | 1.64 | |||
| 25-150 TH | 38 (1.50) | 88.9 | 3/4 (5/8) | 2-7/8 | 1.64 | |||
| 20-175 TH | 44 (1.75) | 73 | 3/4 | 2-3/8 | 2.24 | |||
| 25-175 TH | 44 (1.75) | 88.9 | 3/4 | 2 7/8 | 2.24 | |||
| 25-200 TH | 51 (2.00) | 88.9 | 3/4 | 2-7/8 | 2.91 | |||
| 25-225 TH | 57 (2.25) | 88.9 | 3/4 | 2-7/8 | 3.69 | |||
| 25-250 TH | 64 (2.50) | 88.9 | 3/4 | 3-1/2 | 4.55 | |||
| 30-275 TH | 70 (2.75) | 108 | 7/8 | 3-1/2 | 5.50 | |||
| 35-325 TH | 83 (3.25) | 116 | 7/8 | 4 | 7.70 | |||
| 40-375 TH | 95 (3.75) | 116 | 1 | 4-1/2 | 10.26 | |||
| 35-425 TH | 108 (4.25) | 147 | 1-1/8 | 4 | 13.18 | |||
Features:
1.According to API Spec 11AX
2.The barrel being connected to the tubing is directly run into the well
3.Suitable for the shallow well with shallow depth and high production
4.The plunger is run into the barrel with the sucker rod
