Product Details
Place of Origin: China
Brand Name: Zhongshi
Certification: API, ISO, QHSE
Model Number: Sucker rod pump
Payment & Shipping Terms
Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: Standard exported packing
Delivery Time: 10~15 workdays
Payment Terms: L/C, D/P, T/T, Western Union, D/A
Supply Ability: 1000 SETS/MONTH
Product: |
API Stationary Downhole Pump Barrel |
Material: |
38CrMoA,alloy Steel |
Processing: |
Nickel-phosphorus Plating Process /With Chrome Process |
Application: |
Oil,petroleum Production |
Length: |
As Request |
Plunger Length (ft): |
2-24 |
Product: |
API Stationary Downhole Pump Barrel |
Material: |
38CrMoA,alloy Steel |
Processing: |
Nickel-phosphorus Plating Process /With Chrome Process |
Application: |
Oil,petroleum Production |
Length: |
As Request |
Plunger Length (ft): |
2-24 |
API Stationary Downhole Pump Barrel
Product Desciption
The pump barrel assembly of the tubing pump connected on the tubing string,and with its down to the bottom of the well.
In the process of production, when traveling valve and standing valve appear problems,we can pull the traveling valve and standing valve out the well through the sucker rod string, plunger and the puller ,instead of pull the whole pump and tubing string out of the well, reduce the labor intensity of operation, reduce the operation cost.
Main parts process and material:
1. Pump barrel: plain carbon steel plating (A1), ordinary carbon steel carbonitriding (B1), ordinary carbon steel carburizing (B2), low alloy steel nitride (B5).
2. Plunger: 1045 steel spraying (B1), 1045 steel spraying (B2), 1045 steel chrome plating (A1), 1045 steel double chrome plating (A2).
3. Valve ball and seat: stainless steel (A1), cobalt chromium (B2), tungsten carbide (C1), nickel and carbon compounds (C2), titanium carbide (C3).
4. Other accessories: plain carbon steel, low alloy steel, stainless steel, brass and other materials.
Technical Specification:
| Specification | Length of Plunger | Connecting Tubing | Stroke | Pump constant |
| (mm) | (mm) | (in) | (m) | (m3/d) |
| φ38/57 | 1200 | 2 7/8 | 5.1 | 5.73 |
| φ44/95 | 1200 | 2 7/8 | 5.1 | 18.21 |
