Product Details:
Payment & Shipping Terms:
|
Product Name: | Oilfield Casing Rigid Roller Centralizer | Material: | 65Mn |
---|---|---|---|
Processing: | Forging | Roller: | Depends |
Color: | Red Color | Field: | Well Drilling |
High Light: | 139.7mm Rigid Roller Centralizer,Casing Rigid Roller Centralizer,5 1/2 Inch casing centralizer |
Oilfield Casing Rigid Roller Centralizer
The casing rigid roller centralizer consists of a rigid body, on which machined five spiral blades. There are three or four modified alloy steel, fully heat treated rollers fixed on every spiral blades. The assembly is shown as following fig. Because of rigid body and rolling friction between the rollers and inside of well or casing, the capability of the top wire casing rigid roller centralizer is better than others of all. Recommend to use the tool in deviated holes and horizontal holes
Oilfield Casing Rigid Roller Centralizer Features
Casing centralizer | Min Hole | I.D. | O.D. | OAL |
(mm/inch) | (mm/inch) | (mm/inch) | (mm/inch) | (mm/inch) |
139.7(5-1/2) | 215.9(8-1/2) | 143(5-5/8) | 211(8-5/16) | 260(10-1/4) |
177.8(7) | 215.9(8-1/2) | 181(7-1/8) | 213.4(8-13/32) | 260(10-1/4) |
244.5(9-5/8) | 311.15(12-1/4) | 247.5(9-11/16) | 305.4(12-1/64) | 260(10-1/4) |
339.7(13-3/8) | 406.4(16) | 344(13-35/64) | 402(15-53/64) | 260(10-1/4) |
