Aluminum Alloys Bow Spring Centralizer 20" Oil Well Centralizer

Aluminum Alloys Bow Spring Centralizer 20" Oil Well Centralizer
Aluminum Alloys Bow Spring Centralizer 20" Oil Well Centralizer

Large Image :  Aluminum Alloys Bow Spring Centralizer 20" Oil Well Centralizer

Product Details:

Place of Origin: China
Brand Name: Puyang Zhongshi Group
Certification: API,ISO,QHSE
Model Number: 4 1/2"~20"

Payment & Shipping Terms:

Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: Wooden Box
Delivery Time: depends on quantity
Payment Terms: T/T, MoneyGram
Detailed Product Description
Product: Oilfield Aluminum Alloys Casing Centralizer Material: Aluminium Alloy
Size: 4.5"~20" Or As Request Blade Type: Spiral
Service: OEM Or ODM Application: Well Drilling
High Light:

Aluminum Alloys Bow Spring Centralizer

,

Aluminum Alloys Oil Well Centralizer

,

20" Oil Well Centralizer

Oilfield Aluminum Alloys Casing Centralizer



The fins or blades overlap the entire 360-degree open hole circumference and the reduced flow area between the spirals provides and creates a vortex motion that increases fluid velocity. Even without rotation, the angled fins still induce turbulent flow for improved cutting and filter cake removal. All Centralizers are stove painted or coated with polyester powder.


Oilfield Aluminum Alloys Casing Centralizer Features



  • Suitable for either cased or open hole.
  • Reduced drag when running into hole.
  • Wide vanes distribute load from the casing string into the well bore without gouging.
  • The design of the vanes keeps running forces at a minimum.
  • Vane ends are beveled 30 degrees relative to casing centralizer to provide excellent lead into restrictions



Oilfield Aluminum Alloys Casing Centralizer Specification



Size(inch) ID (mm) OD (mm) Height(mm)
13 3/8 343 400 130
10 3/4 276 308 120
9 5/8 247 308 120
7 5/8 197 243 120
7 180 212 120
5 1/2 143 213 120
5 130 151 120
4 1/2 117 148 100
4 104 118 80
