API 5CT Float Collar And Float Shoe For Oil Well Drilling

Product Details

Place of Origin: Puyang city , Henan province ,China

Brand Name: PUYANGZHONGSHI

Certification: API 5CT 1415

Model Number: API or customized

Payment & Shipping Terms

Minimum Order Quantity: 1pcs

Price: USD50-200$/pcs

Packaging Details: wooden cases

Delivery Time: 7-15work days

Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability: 1000pcs one month

Get Best Price
High Light:

Drilling Float Collar And Float Shoe

,

Oil Well Cement Float Shoe

,

Casing Float Shoe API 5CT

Color:
Blue Or Green
Processing Type:
Forging,Casting,Other
Material:
Carbon Steel,High Manganese Steel,alloy Steel,Inside Are Aluminum Alloy
Type:
Cementing Tools
Product Name:
Oilfield Cementing Tools Casing Float Collar And Float Shoe
Advantage:
High Performance,Wear Resistant
Grade:
K55,J55,L80
Color:
Blue Or Green
Processing Type:
Forging,Casting,Other
Material:
Carbon Steel,High Manganese Steel,alloy Steel,Inside Are Aluminum Alloy
Type:
Cementing Tools
Product Name:
Oilfield Cementing Tools Casing Float Collar And Float Shoe
Advantage:
High Performance,Wear Resistant
Grade:
K55,J55,L80
API 5CT Float Collar And Float Shoe For Oil Well Drilling

Float collar and shoe introduction

Float collar and floate shoe is a kind of casing guide shoe or coupling that can produce buoyancy. Due to the high temperature resistance, good sealing and drillability and convenient connection of float collar and float shoe, they can replace guide shoes, casing shoes, etc. Float collar and shoe can be used not only for general technical casing and reservoir casing, but also for deep wells, ultra deep wells and special process wells.



Parameter of Single Valve Float Collar and Float Shoe:

Place of Origin Puyang,Henan , China (Mainland)
Brand Name China petroleum Equipment
Model Number 5"-13-3/8"
Type Float shoe and float collar
Machine Type Oil production
Certification API 5CT 1415
Material Alloy steel
Processing Type Casting
Use Oil production
Standard API 5CT,API
Thread type STC, LTC, BTC
Float shoe Length 416mm-515mm
Float collar Length 320mm-350mm
MaxO.D 189mm-365mm
Color Red or as your requirement
Forward pressure 30 Mpa
Reverse pressure 35 Mpa
Apply to Different sizes of casing
Name Size(in) Bore O.D.(in) Bore I.D.(in) Min Bore Thread Type lb(in2)
Parameter(in)
Float Collar 5 1/2" 6" 4 3/4" 2" 5 1/2” LCSG 4351
7" 7 5/8" 6 1/4" 2 3/8" 7" LCSG 3626
9 5/8" 10 5/8" 8 5/8" 2 3/8" 9 5/8" LCSG 3626
13 3/8" 14 3/8" 12 3/8" 2 3/8" 13 3/8" LCSG 3626
Float Shoe 5 1/2" 6" 4 3/4" 2" 5 1/2" LCSG 4351
7" 7 5/8" 6 1/4" 2 3/8" 7" LCSG 3626
9 5/8" 10 5/8" 8 5/8" 2 3/8" 9 5/8" LCSG 3626
13 3/8" 14 3/8" 12 3/8" 2 3/8" 13 3/8" LCSG 3626



API 5CT Float Collar And Float Shoe For Oil Well Drilling 0

Company information

Puyang Zhongshi Group co., Ltd. was founded in 1996, which is the restructured enterprise of Central Plains oilfield branch company of SINOPEC . The company registered capital is 60 million yuan, with annual output value 200 million yuan, 580 employees, including more than 160 technical and administrative staff. We have competitive price of our main products like: subsurface sucker rod pump, sucker rod ,drill rod ,pumping unit, cementing tools, wellhead (Christmas Tree), etc, with certificates of API11AX,API11E,API10D,API6A,API5CT,ISO14001 and ISO9001 approved.
