Product Details
Place of Origin: China
Brand Name: PUYANGZHONGSHI
Certification: API 11AX-0061
Model Number: API or customized
Payment & Shipping Terms
Minimum Order Quantity: 10pcs
Price: USD 220-360$/pcs
Packaging Details: standard package
Delivery Time: 30-60 work days
Payment Terms: L/C, D/A, D/P, T/T, Western Union
Supply Ability: 100pcs one month
Standard: |
API 11AX |
Pressure: |
High Pressure,Standard |
Structure: |
Other |
Standard Or Nonstandard: |
Standard |
Color: |
Blue |
Standard: |
API 11AX |
Pressure: |
High Pressure,Standard |
Structure: |
Other |
Standard Or Nonstandard: |
Standard |
Color: |
Blue |
The oil well pump has the following requirements:
(1) It should have sufficient strength and good sealing.
(2) It is required to work reliably and have a long service life. The valve, main plug and pump barrel should be determined from the aspects of structure, material, processing quality and heat treatment process Strict requirements. Improve the wear resistance and corrosion resistance of the tensioning equipment, which can reduce the non production time of the oil well pump and reduce the oil production cost.
(3) It should have high productivity and pump efficiency, and be easy to install, repair and use.
|
型号 Model |
公称直径, mm (in) |
柱塞长度, m Plunger Length(ft) |
冲程, m stroke |
泵常数, m3/d PumpConstant |
连接油管螺纹 Tubing and Thread |
连接抽油杆, in Sucker Rod |
| 20-125TH | 32(1.25) | 1.2-1.8(4-6) | 0.6-7.3 | 1.14 | 2-3/8 | 3/4 |
| 25-125TH | 32(1.25) | 0.6-7.3 | 1.14 | 2-7/8 | 3/4 | |
| 20-150TH | 38(1.50) | 0.6-7.3 | 1.64 | 2-3/8 | 3/4 | |
| 25-150TH | 38(1.50) | 0.6-7.3 | 1.64 | 2-7/8 | 3/4 | |
| 20-175TH | 44(1.75) | 0.6-7.3 | 2.24 | 2-3/8 | 3/4 | |
| 25-175TH | 44(1.75) | 0.6-7.3 | 2.24 | 2-7/8 | 3/4 | |
| 25-200TH | 50(2.00) | 0.6-7.3 | 2.92 | 2-7/8 | 3/4 | |
| 25-225TH | 57(2.25) | 0.6-7.3 | 3.69 | 2 -7/8 | 3/4 | |
| 30-250TH | 63(2.50) | 0.6-7.3 | 4.56 | 3-1.2 | 7/8 | |
| 30-275TH | 70(2.75) | 0.6-7.3 | 5.50 | 3-1/2 | 7/8 | |
| 30-325TH | 83(3.25) | 0.6-7.3 | 7.70 | 4 | 7/8 | |
| 40-375TH | 95(3.75) | 0.6-7.3 | 10.26 | 4-1/2 | 1 |
|
Place of Origin
|
China |
| Brand Name | Puyangzhongshi |
| Model Number | TH |
| Application | Oil and gas |
| Condition | New |
| Warranty | 1 Year |
| Applicable Industries | Energy & Mining, oil and gas |
| Weight (KG) | 50-220 |
| Showroom Location | China |
| Video outgoing-inspection |
Provided
|
| Machinery Test Report | Provided |
| Marketing Type | Ordinary Product |
| Warranty of core components | 1 Year |
| Core Components | Pump, barrel, plunger, valve ball and seat, rod, point |
| Certification | API 11AX-0061 |
Puyang Zhongshi Group Co., Ltd., restructured from SINOPEC in 1997 has 20 years experience on manufacturing petroleum machinery products .The company registered capital is 10 million U.S. dollars, with annual export 30 million U.S. Dollars. We have competitive price of our main products like: subsurface sucker rod pump, sucker rod ,drill rod ,pumping unit, cementing tools, wellhead (Christmas Tree), etc, with certificates of API11AX,API11E,API10D,API6A,API5CT,ISO14001 and ISO9001 approved. We have 9 factories, 580 employees, including more than 160 technicians and engineers.
With 20 years manufacturing experience and more than 10 years exporting experience, our main clients include all oilfields in China such as: Zhongyuan, Daqing, Shengli, Changqing, Nanyang, Karamay, etc and we have exported to more than 30 countries abroad such as: Indonesia, Thailand, Myanmar, Russia, Kazakhstan, Venezuela, Peru, Columbia, Canada, America, Sudan, Egypt, Iran, Australia etc.
We would like to cooperate with friends from all over the world with high quality products and service to achieve mutual development .
