Powerful Coated Spiral Casing Centralizer For Oil Well API

Powerful Coated Spiral Casing Centralizer For Oil Well API
Powerful Coated Spiral Casing Centralizer For Oil Well API Powerful Coated Spiral Casing Centralizer For Oil Well API

Large Image :  Powerful Coated Spiral Casing Centralizer For Oil Well API

Product Details:

Place of Origin: Puyang city , Henan province ,China
Brand Name: PUYANGZHONGSHI
Certification: API 5CT 1415,API 10D
Model Number: API or customized

Payment & Shipping Terms:

Minimum Order Quantity: 10pcs
Price: USD20-80$/pcs
Packaging Details: wooden cases
Delivery Time: 15-20 work days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 1000pcs one month
Detailed Product Description
Type: Cementing Tool Centralizers Size: 5 1/2--20''
Material: Forging And Coating Warranty: 12 Months
Usage: Oil Drilling Feature: High Efficiency
High Light:

Oil Well Casing Centralizer

,

Spiral Oil Well Centralizer

,

Coated Casing Roller Centralizers

Coated Aluminium Alloy Spiral Vane Casing Centralizer



Coated Aluminium Alloy Spiral Vane Casing Centralizer are made of high strength, corrosion resistant cast aluminum. They can be used with corrosion resistant alloy casing strings to avoid the effects of galvanic corrosion. Their spiral blades increase annular turbulence to improve well bore clean out. It is developed specially for horizontal and extended reach wells with lower coefficient of friction over steel centralizers.


Coated Aluminium Alloy Spiral Vane Casing Centralizer Features
  • Application:in deviated and horizontal wells, liner overlaps, and shoe joints.
  • Suitable for either cased or open hole.
  • Vane ends are beveled 30 degrees relative to casing centralizer to provide excellent lead into restrictions and reduced drag when running into hole.
  • Wide vanes distribute load from the casing string into the well bore without gouging.
  • The design of the vanes keeps running forces at a minimum



Coated Aluminium Alloy Spiral Vane Casing Centralizer Specification





Specification casing size (mm) Hole Size (mm) Inner Diameter (mm) Outer Diameter (mm)
4-1/2″×6″ 114 152 118 146
5"×6 5/8" 127 168 131 162
5-1/2″×8-1/2″ 140 216 142 210
7″×8 1/2″ 178 216 182 210
7"× 9-1/2" 178 241 182 235
9-5/8″×12-1/4″ 244 311 248 305
13-3/8″×17-1/2" 340 445 344 439

Powerful Coated Spiral Casing Centralizer For Oil Well API 0

Powerful Coated Spiral Casing Centralizer For Oil Well API 1



Puyang Zhongshi Group Co., Ltd., restructured from SINOPEC in 1997 has 20 years experience on manufacturing petroleum machinery products .The company registered capital is 10 million U.S. dollars, with annual export 30 million U.S. Dollars. We have competitive price of our main products like: subsurface sucker rod pump, sucker rod ,drill rod ,pumping unit, cementing tools, wellhead (Christmas Tree), etc, with certificates of API11AX,API11E,API10D,API6A,API5CT,ISO14001 and ISO9001 approved. We have 9 factories, 580 employees, including more than 160 technicians and engineers.
With 20 years manufacturing experience and more than 10 years exporting experience, our main clients include all oilfields in China such as: Zhongyuan, Daqing, Shengli, Changqing, Nanyang, Karamay, etc and we have exported to more than 30 countries abroad such as: Indonesia, Thailand, Myanmar, Russia, Kazakhstan, Venezuela, Peru, Columbia, Canada, America, Sudan, Egypt, Iran, Australia etc.
We would like to cooperate with friends from all over the world with high quality products and service to achieve mutual development .
