Home > products > Bow Spring Centralizer > Steel Slip On Cementing Wiper Plugs For Oilfield Well Drilling

Steel Slip On Cementing Wiper Plugs For Oilfield Well Drilling

Product Details

Place of Origin: China

Brand Name: Puyang Zhongshi Group

Certification: API,ISO,QHSE

Model Number: 4 1/2"~20"

Payment & Shipping Terms

Minimum Order Quantity: 1

Price: Negotiable

Packaging Details: Wooden Box

Delivery Time: depends on quantity

Payment Terms: T/T, MoneyGram

Get Best Price
High Light:

Oilfield Cementing Wiper Plugs

,

Well Drilling Cementing Wiper Plugs

,

Steel Oilfield Liner Wiper Plug

Product:
Oilfield Cementing Tool Cement Wiper For Well Drilling
Installation:
Slip-on
Material:
Steel
Size:
4 1/2"~36"
Process:
Casting
Application:
Oilfield Cementing Equipment
Product:
Oilfield Cementing Tool Cement Wiper For Well Drilling
Installation:
Slip-on
Material:
Steel
Size:
4 1/2"~36"
Process:
Casting
Application:
Oilfield Cementing Equipment
Steel Slip On Cementing Wiper Plugs For Oilfield Well Drilling

Oilfield Cementing Tool Cement Wiper For Well Drilling



Cement wiper is able to maintain a powerful grip without harming the casing via a draw-bolt tightening mechanism, thus removing the need for a stop collar. This reciprocating wiper is recommended for use with all standard casing grades and versions are available for all standard casing sizes.


Oilfield Cementing Tool Cement Wiper For Well Drilling Features
  • Hinged collar design features a looped cable design.
  • Install by torqueing draw bolt to a maximum of 30ft. -lbs.
  • Parts are manufactured after receipt of order.
  • Other sizes available upon request.

Oilfield Cementing Tool Cement Wiper For Well Drilling Specification

Specification

casing size

(mm)

Outer Diameter

(mm)

Hole Size

(mm)

Inner Diameter (mm)
4-1/2"×6" 114 146 152 118
5"×6 5/8" 127 162 168 131
5-1/2″×8-1/2″ 140 210 216 142
6-5/8″×8-1/2″ 168 210 216 172
7″×8-1/2″ 178 210 216 182
7"× 9-1/2" 178 235 241 182
9-5/8″×12-1/4″ 244 305 311 249
13-3/8″×17-1/2" 340 439 445 344
