Home > products > Bow Spring Centralizer > Oilwell Composite Bow Spring Centralizer For Casing

Oilwell Composite Bow Spring Centralizer For Casing

Product Details

Place of Origin: China

Brand Name: Puyang Zhongshi Group

Certification: API,ISO,QHSE

Model Number: 4 1/2"~36"

Payment & Shipping Terms

Minimum Order Quantity: 1

Price: Negotiable

Packaging Details: Wooden Box

Delivery Time: depends on quantity

Payment Terms: T/T, MoneyGram

Get Best Price
High Light:

Composite Bow Spring Centralizer

,

Bow Spring Centralizer For Casing

,

Composite well casing centralizers

Product:
Oilwell Composite Centralizers For Casing
Material:
Composite
Size:
4 1/2~13 3/8”
Feature:
Without Steel Ring
Blade:
4~12
Vane:
Spiral
Product:
Oilwell Composite Centralizers For Casing
Material:
Composite
Size:
4 1/2~13 3/8”
Feature:
Without Steel Ring
Blade:
4~12
Vane:
Spiral
Oilwell Composite Bow Spring Centralizer For Casing

Oilwell Composite Centralizers for Casing



The Polymer Composite Centralizer is with design of one-piece composite construction and nylon material.Shock and impact resistance in low temperature and low moisture content environment.


Oilwell Composite Centralizers for Casing Features
  • High wear resistance
  • Oil Proof
  • for Horizontal and highly-deviated well

Oilwell Composite Centralizers for Casing Specification

Specification Inner Diameter
(mm)
Height
(mm)
Outer Diameter (mm)
13 3/8"×17 1/2" 345 250/300 438
13-3/8" ×16” 345 250/300 400
10 3/4"×16" 276 250/300 305
9 5/8"×12 1/4" 247 250/300 305
7 5/8"×9 1/2" 196 250/300 235
7"× 9 7/8" 181 250/300 245
7"× 8 1/2" 181 250 210
7"× 9 1/2" 181 250 235
5 1/2"× 8 1/2" 141 250 210
4 1/2"×6" 117 250 148
