20-150-RHAC-10-2-1-1 Sucker Rod Pump Heavy Wall Barrel

20-150-RHAC-10-2-1-1 Sucker Rod Pump Heavy Wall Barrel
20-150-RHAC-10-2-1-1 Sucker Rod Pump Heavy Wall Barrel

Large Image :  20-150-RHAC-10-2-1-1 Sucker Rod Pump Heavy Wall Barrel

Product Details:

Place of Origin: Puyang city , Henan province ,China
Brand Name: PUYANGZHONGSHI
Certification: API 11AX-0061
Model Number: API or customized

Payment & Shipping Terms:

Minimum Order Quantity: 1pcs
Price: USD 200-300$/pcs
Packaging Details: wooden cases
Delivery Time: 30-50 work days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 100pcs one month
Detailed Product Description
Pump Model: RHAC Seating Type: Cup Seating
Seating Location: Top Barrel Type: Heavy Wall
Barrel Coating: Chrome Plating Barrel Material: Quality High Carbon Steel
Plunger Material: Quality High Carbon Steel Application: Oil Production
High Light:

RHAC Sucker Rod Pump

,

Heavy Wall Barrel Sucker Rod Pump

,

Heavy Wall Barrel srp pump

20-150-RHAC-10-2-1-1 Heavy Wall Barrel Sucker Rod Pump



Heavy wall barrel sucker rod pump description:



While there are only two main types of pumps standardized by API, there are four different types of rod pumps. These are classified by the type of barrel (standing or traveling) and where the pump is anchored (top or bottom). API Spec. 11AX. shows the letter designations for the various types of rod and tubing pumps that are available for different barrel thicknesses and either metal or soft-packed plungers.

The inner surface of the pump barrel is processed with carbonization quenching and chrome plating technology, the plunger surface is processed with thermal metal spraying technology. The pump ranges from Ф28 mm to Ф108 mm, and it has be formed a series products as sand control, anti-gas, heavy oil, deep pumping, inclined shaft, anti-corrosion and etc.

API-RHAC, Rod, Stationary Heavy Wall Barrel, Cup Top Anchor Pump
API-RHBM, Rod, Stationary Heavy Wall Barrel, Mechanical Bottom Anchor Pump
API-RHBC, Rod, Stationary Heavy Wall Barrel, Cup Bottom Anchor Pump





RH series rod pump technical table:

RH pump model

Nominal OD(in)

Plunger Length(ft)

Stroke(m)

Pump Constant

m3/d

Tubing and Thread

Sucker Rod in

25-112RHAC/M 28(1.12)

1.2–1.8

(4–6)

≤9.3 0.92 2-7/8 3/4
20-125RHAC/M 32(1.25) 1.14 2-3/8 3/4
25-150RHAC/M 38(1.50) 1.64 2-7/8 3/4
25-175RHAC/M 44(1.75) 2.24 2-7/8 3/4
30-225RHAC/M 57(2.25) 3.69 3-7/8 3/4
20-125RHBC/M 32(1.25) 1.14 2-3/8 3/4
25-150RHBC/M 38(1.50) 1.64 2-7/8 3/4
25-175RHBC/M 44(1.75) 2.24 2-7/8 3/4
30-225RHBC/M 57(2.25) 3.69 3-1/2 3/4
20-125RHTC/M 32(1.25) 1.14 2-3/8 3/4
25-150RHTC/M 38(1.50) 1.64 2-7/8 3/4
25-175RHTC/M 44(1.75) 2.24 2-7/8 3/4
30-225RHTC/M 57(2.25) 3.69 3-1/2 3/4





Puyang Zhongshi Group co., Ltd. was founded in 1996, which is the restructured enterprise of Central Plains oilfield branch company of SINOPEC . The company registered capital is 60.83 million yuan, with annual output value 200 million yuan, 580 employees, including

more than 160 technical and administrative staff . Oil machinery is our main products, the leading products include pumping unit, subsurface sucker rod pump, wellhead (Christmas Tree), pressure vessels, drilling solid control series products and cementing accessories. We had attained ISO 9001 in 1998 and API Certificates in 2002 .



Pump photo:

20-150-RHAC-10-2-1-1 Sucker Rod Pump Heavy Wall Barrel 0
