Product Details
Place of Origin: China
Brand Name: Puyang Zhongshi Group
Certification: API,ISO,QHSE
Model Number: 4 1/2"~36"
Payment & Shipping Terms
Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: Wooden Box
Delivery Time: depends on quantity
Payment Terms: T/T, MoneyGram
Product: |
Cement Float Equipment With Single Valve |
API Thread: |
STC/BTC/LTC |
Valve: |
Single Or Double |
Usage: |
Well Drilling |
Application: |
For Distributing The Cementing Slurry And Washing Out Bridges |
Grade: |
N80, K55, J55, L80, P110 |
Product: |
Cement Float Equipment With Single Valve |
API Thread: |
STC/BTC/LTC |
Valve: |
Single Or Double |
Usage: |
Well Drilling |
Application: |
For Distributing The Cementing Slurry And Washing Out Bridges |
Grade: |
N80, K55, J55, L80, P110 |
Cement Float Equipment with Single Valve
Float equipment guides the casing to total depth and prevents contaminated mud from entering the casing which enhancement of fluid turbulence helps in preventing channeling near the shoe thus aiding in hole cleaning,with added assurance that circulation of fluid is not interrupted when casing becomes plugged during running or is rested on bottom.
.
Float collars and float shoes are tested and rated in compliance with API.
All machining of float collars&shoes is processed on CNC machines.
Available to different material, such as K-55, L-80, N-80, C-95, T-95, and P110.
Used for distributing the cementing slurry and washing out briges
| Specification(in) | Min.Dia. | Total | O.D. | I.D. | Working Pressure | Connection Type | |
| (mm) | Length | (mm) | (mm) | ||||
| Float Collar | 5" | 50 | 500 | 141.3 | 110 | 21~35 | BTC/LTC/BCSG |
| 5 1/2" | 55 | 530 | 153.67 | 112 | 21~35 | BTC/LTC/BCSG | |
| 7" | 77 | 586 | 194.46 | 162.5 | 21~35 | BTC/LTC/BCSG | |
| 9 5/8" | 77 | 720 | 270 | 225 | 21~35 | BTC/LTC/BCSG | |
| 13 3/8" | 77 | 720 | 365 | 319 | 21~35 | BTC/LTC/BCSG | |
| 20" | 77 | 720 | 533.4 | 475 | 21~35 | BTC/LTC/BCSG | |
| Float Shoe |
5" | 50 | 495 | 140.3 | 110 | 21~35 | BTC/LTC/BCSG |
| 5 1/2" | 55 | 514 | 153.67 | 112 | 21~35 | BTC/LTC/BCSG | |
| 7" | 77 | 533 | 194.46 | 162.5 | 21~35 | BTC/LTC/BCSG | |
| 9 5/8" | 77 | 550 | 269.88 | 225 | 21~35 | BTC/LTC/BCSG | |
| 13 3/8" | 77 | 550 | 339.7 | 319 | 21~35 | BTC/LTC/BCSG | |
| 20" | 77 | 652 | 534 | 475 | 21~35 | BTC/LTC/BCSG | |
