Product Details
Place of Origin: China
Brand Name: Puyang Zhongshi Group
Certification: API,ISO,QHSE
Model Number: 4 1/2"~36"
Payment & Shipping Terms
Minimum Order Quantity: 5
Price: Negotiable
Packaging Details: Wooden Box
Delivery Time: depends on quantity
Payment Terms: T/T, MoneyGram
Product: |
55KW Centrifugal Pump Spare Parts |
Flow Rate: |
120m3/h |
120m3/h: |
1450/1750 |
Voltage: |
220V/380V/400v/415v |
Application: |
Oilfield Solid Control |
Product: |
55KW Centrifugal Pump Spare Parts |
Flow Rate: |
120m3/h |
120m3/h: |
1450/1750 |
Voltage: |
220V/380V/400v/415v |
Application: |
Oilfield Solid Control |
55KW Centrifugal Pump Spare Parts
Centrifugal pumps are mainly suitable for conveying drilling fluid or industrial suspension slurry, and are used to pump viscous and corrosive liquids by using modern design theory. Compared with the general pump, the centrifugal pump of our company has the following excellent performance: high temperature, large flow, long service life, convenient maintenance, significant energy saving, high reliability. It is widely used in onshore and offshore drilling all over the world.
55KW Centrifugal Pump Spare Parts Features :
55KW Centrifugal Pump Spare Parts Specification
Model | Flow | Lift | Efficiency | NPSH | Power | Speed | Dimension | Weight | |
m3/h | GPM | (m) | (%) | (m) | (kW) | (rpm) | (mm) | (kg) | |
SB8x6-14 | 320 | 1408 | 40 | 65 | 4 | 75 | 1480 | 1980×660×1030 | 1105 |
SB8x6-13 | 290 | 1276 | 33 | 64 | 4.5 | 55 | 1480 | 1910×660×930 | 945 |
SB6x5-14 | 200 | 880 | 40 | 62 | 3 | 55 | 1480 | 1870×570×930 | 900 |
SB6x5-13 | 180 | 792 | 34 | 60 | 3 | 45 | 1475 | 1820×570×830 | 765 |
SB6x5-12 | 160 | 704 | 30 | 60 | 3 | 30 | 1470 | 1740×570×830 | 700 |
SB5x4-14 | 120 | 528 | 40 | 56 | 4.6 | 37 | 1475 | 1770×480×830 | 710 |
SB5x4-13 | 90 | 396 | 40 | 56 | 4.5 | 30 | 1470 | 1710×480×830 | 650 |
SB5x4-12 | 90 | 396 | 30 | 56 | 4.5 | 22 | 1470 | 1650×480×830 | 600 |
SB4x3-13 | 50 | 220 | 40 | 48 | 4.5 | 18.5 | 1470 | 1610×500×750 | 560 |
SB4x3-12 | 45 | 198 | 30 | 47 | 4 | 15 | 1460 | 1570×500×750 | 510 |
SB3x2-13 | 25 | 110 | 35 | 40 | 3 | 11 | 1460 | 1470×480×750 | 450 |
SB3x2-12 | 23 | 101 | 29 | 39 | 3m | 7.5 | 1440 | 1360×480×700 | 400 |
SB3x2-11 | 20 | 88 | 23 | 39 | 3m | 5.5 | 1440 | 1320×480×700 | 390 |
SB8x6-12 | 335 | 1474 | 43 | 66 | 4.8 | 75 | 1780 | 1980×660×1030 | 1105 |
SB6x5-12 | 196 | 862 | 48 | 61 | 3 | 55 | 1780 | 1870×570×930 | 900 |
SB5x4-14 | 149 | 656 | 61 | 58 | 4.6 | 45 | 1760 | 1800×480×830 | 715 |
SB5x4-12 | 120 | 528 | 40 | 58 | 4.6 | 37 | 1760 | 1770×480×830 | 710 |
SB5x4-11 | 112 | 493 | 45 | 57 | 4.2 | 30 | 1760 | 1710×480×830 | 650 |
SB5x4-10 | 105 | 462 | 30 | 57 | 4 | 22 | 1750 | 1650×480×830 | 600 |
SB4x3-12 | 55 | 242 | 46 | 48 | 4 | 18.5 | 1750 | 1610×500×750 | 560 |
SB4x3-11 | 54 | 238 | 35 | 47 | 4 | 15 | 1750 | 1570×500×700 | 510 |
SB3x2-12 | 28 | 123 | 45 | 40 | 3.1 | 11 | 1750 | 1370×480×700 | 450 |
SB3x2-11 | 25 | 110 | 35 | 41 | 3.1 | 7.5 | 1750 | 1360×480×700 | 400 |
Remark: 1.The motor power of centrifugal pump chosen is according to drilling mud specific gravity 1.2g/cm3. |
