Product Details
Place of Origin: China,Henan
Brand Name: ZS
Certification: API 11AX
Model Number: 20-125 To 30-250
Payment & Shipping Terms
Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: nude or wooden case
Delivery Time: 15 work days
Payment Terms: T/T
Supply Ability: 1000sets/month
Material: |
Carbon Steel |
Light: |
Customized |
Certification: |
API 11AX |
Warranty: |
1 Year |
Processing Type: |
Forging |
Color: |
Customized |
Application: |
Energy & Mining, Oil Mining |
Core Component: |
Bearing, Pressure Vessel, Gear, Pump |
Connection: |
API |
Flow Rate: |
0-100 GPM |
Power Source: |
Electric |
Product Name: |
Sucker Rod Pump |
Pump Pressure: |
1000 PSI |
Material: |
Carbon Steel |
Light: |
Customized |
Certification: |
API 11AX |
Warranty: |
1 Year |
Processing Type: |
Forging |
Color: |
Customized |
Application: |
Energy & Mining, Oil Mining |
Core Component: |
Bearing, Pressure Vessel, Gear, Pump |
Connection: |
API |
Flow Rate: |
0-100 GPM |
Power Source: |
Electric |
Product Name: |
Sucker Rod Pump |
Pump Pressure: |
1000 PSI |
Sucker Rod Pumps
Sucker Rod pump is also known as insert rod pump, it is one type of the conventional sucker rod pumps. The rod pump is connected to the sucker rod directly, it can be pulled out with sucker rod and does not influence the tubing, so the well inspection and workover is more convenient. It can save half times and reduce cost of the pumping test, thus the rod pump is suitable for the deeper well.
Shengji began to manufacture rod pump in the 1960s and we are the main insert and rod pump supplier in China. Our rod pump is strictly conforming to API SPEC 11AX (or GB18607) standard.
Depending on the wall thickness of the barrel, the rod pump can be classified as either a thin wall rod pump or a thick wall rod pump. At Shengji, we manufacture these insert rod pumps according to different requirements of customer’s.
Subsurface Rod Pumps
| Specification | Nominal Pump Bore (in) | Plunger Length(ft) | Max.O.D.(mm) | Rod(in) | Tubing(in) | Pump Constant (m3/d) | Stroke (m) |
| 20-112RHBC | 1.12 | 4~6 | 46.7 | 3/4 | 2 3/8 | 0.92 | ≤7.5 |
| 20-112RHBM | 44.7 | ||||||
| 20-125RHBC | 1.25 | 47.5 | 3/4 | 2 3/8 | 1.14 | ||
| 20-125RHBM | 44.7 | ||||||
| 25-150RHBC | 1.5 | 59.5 | 3/4 | 2 7/8 | 1.64 | ||
| 25-150RHBM | 55.6 | ||||||
| 25-175RHBC | 1.75 | 59.5 | 3/4 | 2 7/8 | 2.24 | ||
| 25-175RHBM | 55.6 | ||||||
| 30-225RHBC | 2.25 | 72.1 | 3/4 | 3 1/2 | 3.69 | ||
| 30-225RHBM | 71.7 |
Subsurface Tubing Pump
| Pump designation | Pump Bore(in) | Length of Plunger (mm) | Range of Stroke (mm) | Pump Constant (m3/d) | Size of matched tubing (in) | Size of connecting Sucker Rod(mm) |
| 25-125 | 1.25 | 600-1200 | 600-1200 | 1.14 | 2-1/2 2-7/8 | 16 |
| 25-150 | 1.5 | 1.642 | 2-1/2 2-7/8 | 16 | ||
| 25-175 | 1.75 | 2.235 | 2-1/2 2-7/8 | 16 | ||
| 20-175 | ||||||
| 25-225 | 2.25 | 3.694 | 2-7/8 | 19 | ||
| 25-275 | 2.75 | 5.518 | 2-7/8 | 22 | ||
| 30-275 | 2.75 | 5.518 | 3-1/2 | 22 | ||
| 30-325 | 3.25 | 7.707 | 3-1/2 | 22 | ||
| 30-375 | 3.75 | 10.261 | 3-1/2 | 25 | ||
| 40-375 | 3.75 | 10.261 | 4 | 25 |
|
Type |
Main parameters | |||||
|
Dia (mm) |
Length pump barrel(m) |
Length of stroke(m) |
Length of extension(m) |
Tubing pipe thread |
Connect of sucker rod |
|
|
Rod pump |
Ø31.8 |
2.1 2.4 2.7 3.0 3.3 3.6 3.9 4.2 4.5 4.8 5.7 6.0 7.3 8.0 9.1 |
1.5- 6
|
0.3
0.6
0.9 |
2-3/8” | CYG16 |
| Ø38.1 |
2-3/8” 2-7/8” |
CYG19 | ||||
| Ø44.45 |
2-3/8” 2-7/8” |
CYG19 | ||||
| Ø57.15 | 2-7/8” | CYG19 | ||||
|
Tubing pump |
Ø31.8 |
1.5- 7.8 |
0.3
0.6
0.9 |
2-3/8” | CYG16 | |
| Ø38.1 |
2-3/8” 2-7/8” |
CYG16 | ||||
| Ø44.45 |
2-3/8” 2-7/8” |
CYG16 | ||||
| Ø57.15 | 2-7/8” | CYG19 | ||||
| Ø69.85 | 3-1/2” | CYG22 | ||||
| Ø95.25 | 4-1/2” |
CYG25 |
||||
Main parts process and material:
Pump barrel: plain carbon steel plating (A1), ordinary carbon steel carbonitriding (B1), ordinary carbon steel carburizing (B2), low alloy steel nitride (B5).
Plunger: 1045 steel spraying (B1), 1045 steel spraying (B2), 1045 steel chrome plating (A1), 1045 steel double chrome plating (A2).
Valve ball and seat: stainless steel (A1), cobalt chromium (B2), tungsten carbide (C1), nickel and carbon compounds (C2), titanium carbide (C3).
Other accessories: plain carbon steel, low alloy steel, stainless steel, brass and other materials.
Puyang Zhongshi Group Co., Ltd is a professional manufacturer of various oilfield equipments and cementing accessories since 1997, restructured enterprise of SINOPEC. Our group have 10 years export experience and 9 subsidiary factories, more than 500 employees. We are the first-class supplier of resources market of SINOPEC and CNPC.
We have the certificates of API 5CT, API 10D, API 11E, API 6A, API 11AX, ISO 9001 and ISO 14001. Our foreign customers are mainly from America, Central Asia, Russia, Southeast Asia, Middle East, etc.
