Product Details
Place of Origin: China,Henan
Brand Name: ZS
Certification: API 11AX
Model Number: 20-125 To 30-250
Payment & Shipping Terms
Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: nude or wooden case
Delivery Time: 15 work days
Payment Terms: T/T
Supply Ability: 1000sets/month
Material: |
Chromium |
Certification: |
API 11AX |
Warranty: |
1 Year |
Processing Type: |
Forging |
Color: |
Customized |
Application: |
Energy & Mining, Oil Mining |
The Connecting Rod: |
CYG19.1 |
Material: |
Chromium |
Certification: |
API 11AX |
Warranty: |
1 Year |
Processing Type: |
Forging |
Color: |
Customized |
Application: |
Energy & Mining, Oil Mining |
The Connecting Rod: |
CYG19.1 |
API 11AX sucker rod pump
Description of oil pump
We can provide API pump and special pump
API pump: RHAC, RHBM, RHAM , RTH(B)C, TH(B)M, RWBM, RWBC, RWAM, RWAC R, RHBM-A, RHBC R
The pump we provide offers several key features:
1. Enhanced Pump Barrel: The inner surface of the pump barrel is treated with a carbonization quench and chrome plating technology. This process improves the durability and longevity of the pump, making it more resistant to wear and corrosion.
2. Efficient Plunger Surface: The plunger surface undergoes thermal metal spraying technology, which further enhances its resistance to wear and corrosion. This ensures optimal performance and extends the lifespan of the pump.
3. High Performance: The pump is designed to meet the requirements of long stroke, high speed, and deep oil production. It is engineered to handle demanding conditions and deliver efficient pumping.
4. Advantages in Efficiency and Displacement: The pump boasts high pumping efficiency, allowing for improved oil production rates. It also offers a large displacement, ensuring effective fluid movement.
5. Durability and Easy Maintenance: The pump is built to withstand rigorous operating conditions, ensuring long-lasting operation. Additionally, it is designed with easy repairability in mind, simplifying maintenance tasks.
6. Compliance and Certification: The pump adheres to the API SPEC 11AX standard, guaranteeing its quality and performance. It has also obtained the certificate of authority to use the official API monogram, further confirming its adherence to industry standards.
PUMP main parts process and material:
Pump barrel: plain carbon steel plating (A1), ordinary carbon steel carbonitriding (B1), ordinary carbon steel carburizing (B2), low alloy steel nitride (B5).
Plunger options:
- Plunger coating: B1 - 1045 steel spraying
- Plunger coating: B2 - 1045 steel spraying
- Plunger coating: A1 - 1045 steel chrome plating
- Plunger coating: A2 - 1045 steel double chrome plating
Valve ball and seat options:
- Valve ball and seat material: A1 - stainless steel
- Valve ball and seat material: B2 - cobalt chromium
- Valve ball and seat material: C1 - tungsten carbide
- Valve ball and seat material: C2 - nickel and carbon compounds
- Valve ball and seat material: C3 - titanium carbide
Other accessories options:
- Other accessories materials: plain carbon steel
- Other accessories materials: low alloy steel
- Other accessories materials: stainless steel
- Other accessories materials: brass
- Other accessories materials: other materials as specified.
Technical parameters of pump
|
Type |
Main parameters | |||||
|
Dia (mm) |
Length pump barrel(m) |
Length of stroke(m) |
Length of extension(m) |
Tubing pipe thread |
Connect of sucker rod |
|
|
Rod pump |
Ø31.8 |
2.1 2.4 2.7 3.0 3.3 3.6 3.9 4.2 4.5 4.8 5.7 6.0 7.3 8.0 9.1 |
1.5- 6
|
0.3
0.6
0.9 |
2-3/8” | CYG16 |
| Ø38.1 |
2-3/8” 2-7/8” |
CYG19 | ||||
| Ø44.45 |
2-3/8” 2-7/8” |
CYG19 | ||||
| Ø57.15 | 2-7/8” | CYG19 | ||||
|
Tubing pump |
Ø31.8 |
1.5- 7.8 |
0.3
0.6
0.9 |
2-3/8” | CYG16 | |
| Ø38.1 |
2-3/8” 2-7/8” |
CYG16 | ||||
| Ø44.45 |
2-3/8” 2-7/8” |
CYG16 | ||||
| Ø57.15 | 2-7/8” | CYG19 | ||||
| Ø69.85 | 3-1/2” | CYG22 | ||||
| Ø95.25 | 4-1/2” | CYG25 | ||||
Puyang Zhongshi Group Co., Ltd, established in 1997 and restructured as an enterprise of Sinopec, is a reputable manufacturer specializing in various oilfield equipment and cementing accessories. Over the course of 10 years, our group has gained valuable export experience and established nine subsidiary factories, employing more than 500 individuals.
We proudly serve as a first-class supplier for the resources market of Sinopec and CNPC. With our API 5CT, API 10D, API 11E, API 6A, API 11AX, ISO 9001, and ISO 14001 certifications, we adhere to top-quality standards in our production processes. Our customers, located in America, Central Asia, Russia, Southeast Asia, the Middle East, and other regions, have benefited from our premium products.
