Product Details
Place of Origin: China,Henan
Brand Name: ZS
Certification: API 11AX
Model Number: 20-125 To 30-250
Payment & Shipping Terms
Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: nude or wooden case
Delivery Time: 15 work days
Payment Terms: T/T
Supply Ability: 1000sets/month
Material: |
Chromium |
Light: |
Customized |
Certification: |
API 11AX |
Warranty: |
1 Year |
Processing Type: |
Forging |
Color: |
Customized |
Fluid Type: |
Oil |
Pressure Rating: |
High |
Valve Pressure Rating: |
High |
Valve Type: |
Check Valve |
Material: |
Chromium |
Light: |
Customized |
Certification: |
API 11AX |
Warranty: |
1 Year |
Processing Type: |
Forging |
Color: |
Customized |
Fluid Type: |
Oil |
Pressure Rating: |
High |
Valve Pressure Rating: |
High |
Valve Type: |
Check Valve |
API 11AX sucker rod pump
API 11AX Downhole Insert Rod Sucker Rod Pump For Deep Oil Well
Product Features:
For some large production wells, larger bore of tubing pump can be worked if the on-off connector is installed. Tubing pump is the strongest pump. It has large flowing area for fluid and it is suitable for producing viscosity oil.
Stationary Heavy Wall, Tubing Pump, its standing valve can not be pulled out.
1.High quality with competitive price
2.High efficiency of sucking oil
3.anti-corrosive and wear-resisting
| Tubing Size | 2-7/8" | 3-1/2" | 3-1/2" |
| Pump Diameter | 2 1/4"-1 1/2" | 2 3/4"-1 1/2" | 2 3/4"-1 3/4" |
| Barrel OD | 4.500" | 5.250" | 5.250" |
| Sucker Rod thread | 3/4" | 7/8" | 7/8" |
| Connecting Tubing Thread | 2-7/8"-8EU | 3-1/2"-8EU | 3-1/2"-8EU |
| Code | 25-225/150PFK | 30-275/150PFK | 30-275/175PFK |
| Pump Diameter | 2 1/4"-1 1/2" | 2 3/4"-1 1/2" | 2 3/4"-1 3/4" |
| Pump Constant | 0.327 | 0.618 | 0.524 |
Our Oil Well Pump Plant, annual output of pump reaches to 2000sets, besides tubing pump and rod pump confirm to API standard, we have researched and developed sand proofing pump, thick oil use pump, airlock proofing pump and other special oil well pump.
Technical parameters of pump:
|
Type |
Main parameters | |||||
|
Dia (mm) |
Length pump barrel(m) |
Length of stroke(m) |
Length of extension(m) |
Tubing pipe thread |
Connect of sucker rod |
|
|
Rod pump |
Ø31.8 |
2.1 2.4 2.7 3.0 3.3 3.6 3.9 4.2 4.5 4.8 5.7 6.0 7.3 8.0 9.1 |
1.5- 6
|
0.3
0.6
0.9 |
2-3/8” | CYG16 |
| Ø38.1 |
2-3/8” 2-7/8” |
CYG19 | ||||
| Ø44.45 |
2-3/8” 2-7/8” |
CYG19 | ||||
| Ø57.15 | 2-7/8” | CYG19 | ||||
|
Tubing pump |
Ø31.8 |
1.5- 7.8 |
0.3
0.6
0.9 |
2-3/8” | CYG16 | |
| Ø38.1 |
2-3/8” 2-7/8” |
CYG16 | ||||
| Ø44.45 |
2-3/8” 2-7/8” |
CYG16 | ||||
| Ø57.15 | 2-7/8” | CYG19 | ||||
| Ø69.85 | 3-1/2” | CYG22 | ||||
| Ø95.25 | 4-1/2” | CYG25 | ||||
Puyang Zhongshi Group Co., Ltd is a professional manufacturer of various oilfield equipments and cementing accessories since 1997, restructured enterprise of SINOPEC. Our group have 10 years export experience and 9 subsidiary factories, more than 500 employees. We are the first-class supplier of resources market of SINOPEC and CNPC.
We have the certificates of API 5CT, API 10D, API 11E, API 6A, API 11AX, ISO 9001 and ISO 14001. Our foreign customers are mainly from America, Central Asia, Russia, Southeast Asia, Middle East, etc.
