Product Details
Place of Origin: China,Henan
Brand Name: ZS
Certification: API 11AX
Model Number: 5-1/2"X8-1/2"to20"X26"
Payment & Shipping Terms
Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: Metal or wooden case
Delivery Time: 15 work days
Payment Terms: T/T
Supply Ability: 1000sets/month
Type: |
Bow Type Spring Centralizer |
Material: |
Stainless Steel |
Central Multimedia: |
Central Machinery Parts |
Central Hydraulics Scissor Lift: |
Toyota Central Locking System |
Weight (KG): |
10 |
Use: |
Well Drilling |
Color: |
Customized |
Type: |
Bow Type Spring Centralizer |
Material: |
Stainless Steel |
Central Multimedia: |
Central Machinery Parts |
Central Hydraulics Scissor Lift: |
Toyota Central Locking System |
Weight (KG): |
10 |
Use: |
Well Drilling |
Color: |
Customized |
Bow Spring Centalize(C01):
The Non-Welded Bow Spring Centralizers are made under the sate af art Enineering Techniques and rugged quality system. They are developed to exceed API 10D specification to be used under most demanding condition. These Centralizers are designed for High Restoring Forse and Low Starting Force for centralizing the casing pipe in a Vertical, Horizontal and Deviated well.
Technical Parameter | ||||||
Spring Casing Centralizer | Size(In) | OD(mm) | IN(mm) | Height(mm) | Max Start-up Force(N) | Min Reset Force(N) |
20" | 680 | 512 | 575 | ≤16725 | ≥8363 | |
13-3/8" | 455 | 342 | 560 | ≤10853 | ≥5427 | |
9-5/8"*12-1/4" | 335 | 248 | 560 | ≤7117 | ≥7117 | |
7" | 235 | 181 | 560 | ≤4626 | ≥4626 | |
6-5/8"*8-3/4" | 238 | 171 | 560 | ≤4270 | ≥4270 | |
5-1/2”*8-1/2” | 235 | 142 | 560 | ≤2758 | ≥2758 |
Rigid Centralizer | 13-3/8" | 437 | 344 | 180 |
9-5/8"*12-1/4" | 305 | 248 | 120 | |
7" | 210 | 182 | 120 | |
6-5/8"*8-3/4" | 215 | 171 | 120 | |
5-1/2"*8-1/2" | 210 | 142 | 120 |
Rigid Roller centralizer used in deep water Horizon Well packing: wooden case
All products purchased in our company are guaranteed to keep in good repair for one year. If quality problems happen in guarantee period, our company will maintain for free. Additionally, our company provides technical support and fittings for life. After-sales service isn't restricted by time and we will assign technical personnel to solve your problems immediately after receiving telephone and hear feedback idea of users and deal with them in time. If you are caught in some problems when using our products, welcome to contact us at any time.
· Zhongshi Group is the API certification enterprise for 15 years;
· ISO9001 quality management system;
· We provide on-site technical service,no matter when and where.
A: We are factory.
A: Generally it is 1-5days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity.
A: Payment<=1000USD, 100% in advance.
