API Casing Head Deep Well Oil Drilling Equipment Wellhead Down Hole Tools

Product Details

Place of Origin: China,Henan

Brand Name: ZS

Certification: API

Model Number: 2000psi to 20000 pis

Payment & Shipping Terms

Minimum Order Quantity: 1

Price: Negotiable

Packaging Details: Metal or wooden case

Delivery Time: 15 work days

Payment Terms: T/T

Supply Ability: 1000sets/month

Get Best Price
High Light:

API Casing Head Down Hole Tools

,

Wellhead Down Hole Tools

,

Forging Deep Well Oil Drilling Equipment

Features:
X-mas Tree
Application:
Oilfield Cementing
Warranty:
1.5 Years
Work Pressure:
2000~15000 PSI
Certification:
API
Core Components:
Bearing, Gearbox, Pressure Vessel
Processing Type:
Forging
Production Capacity:
1000 Sets/year
Certificate:
ISO, API, Etc.
MOQ:
1 Piece
Material:
Carbon Steel, Alloy Steel, Stainless Steel, Etc.
Features:
X-mas Tree
Application:
Oilfield Cementing
Warranty:
1.5 Years
Work Pressure:
2000~15000 PSI
Certification:
API
Core Components:
Bearing, Gearbox, Pressure Vessel
Processing Type:
Forging
Production Capacity:
1000 Sets/year
Certificate:
ISO, API, Etc.
MOQ:
1 Piece
Material:
Carbon Steel, Alloy Steel, Stainless Steel, Etc.
API Casing Head Deep Well Oil Drilling Equipment Wellhead Down Hole Tools

Oil Gas Production Christmas Trees

1. Casing Head - Bottom Slip Connection

Key Features:
(1) Connects surface casing using WD slip.
(2) Incorporates a BT secondary seal structure.
(3) Eliminates the need for precise length calculations of the casing string.
(4) Not affected by surrounding environmental factors or climate conditions.
(5) Installation is easy, fast, and reliable.

This casing head design is suitable for various sizes of casing, such as 30", 20", 13-3/8", 12-1/4", 9-5/8", 7", and 5-1/2". It can accommodate different types of casing threads, including CSG, LCSG, BCSG, TM, for the connection between the casing head and surface casing.

2. Casing Head - Bottom Thread Connection

Features:
(1) The bottom of the casing head connects to surface casing using various types of threads, such as CSG, LCSG, BCSG, TM, etc.
(2) Installation is convenient, rapid, and operationally safe and reliable.

3. Casing Head - Bottom Welded Connection

Key Features:
(1) The bottom of the casing head connects to the surface casing through welding.
(2) Includes a pressure test hole in the welding annular space to assess the effectiveness of the welding.

Technical parameter:



Top flange Top flange Top flange Top flange
11"×2000psi (279.4mm×14MPa) 11"×2000psi (279.4mm×14MPa) 11"×5000psi (279.4mm×35MPa) 13-5/8"×5000psi (346.1mm×35MPa)
11"×2000psi (279.4mm×14MPa) 13-5/8"×2000psi (346.1mm×14MPa) 11"×10000psi (279.4mm×70MPa) 13-5/8"×5000psi (346.1mm×35MPa)
11"×3000psi (279.4mm×21MPa) 11"×3000psi (279.4mm×21MPa) 11"×15000psi (279.4mm×105MPa) 13-5/8"×5000psi (346.1mm×35MPa)
11"×3000psi (279.4mm×21MPa) 13-5/8"×2000psi (346.1mm×14MPa) 13-5/8"×5000psi (346.1mm×35MPa) 21-1/14"×2000psi (539.8mm×14MPa)
11"×3000psi (279.4mm×21MPa) 13-5/8"×3000psi (346.1mm×21MPa) 13-5/8"×10000psi (346.1mm×70MPa) 13-5/8"×5000psi (346.1mm×35MPa)
11"×5000psi (279.4mm×35MPa) 13-5/8"×3000psi (346.1mm×21MPa) 13-5/8"×15000psi (346.1mm×105MPa) 13-5/8"×5000psi (346.1mm×35MPa)
