API 11AX Oilfield Rod Pump Downhole Pump With Chrome Plated Pump Barrel

Name: API 11AX Oilfield Rod Pump Downhole Pump With Chrome Plated Pump Barrel
Brand: Puyang Zhongshi Group Co., Ltd.
SKU: RWBM
Price: 19,525.00 USD
Availability: InStock

Product Details

Place of Origin: China

Brand Name: Zhongshi

Certification: API, ISO, QHSE

Model Number: RWBM

Payment & Shipping Terms

Minimum Order Quantity: 1 set

Price: Negotiable

Packaging Details: Standard exported packing

Delivery Time: 10~15 workdays

Payment Terms: L/C, D/P, T/T, Western Union, D/A

Supply Ability: 1000 SETS/MONTH

Get Best Price

Product Details

Product Description

Highlight:
                                                                                                                                                                                                                                                API 11AX Oilfield Rod Pump, downhole pump Oilfield Rod Pump


Material:	Carbon Steel	Machine Type:	Petroleum Machinery
Application:	Petroleum Production	Color:	Required
Usage:	Oil Field	Type:	Sucker Rod,Rod Pump

Material:	Carbon Steel
Machine Type:	Petroleum Machinery
Application:	Petroleum Production
Color:	Required
Usage:	Oil Field
Type:	Sucker Rod,Rod Pump

API 11AX Oilfield Rod Pump Downhole Pump With Chrome Plated Pump Barrel

API 11AX Oilfield Rod Pump downhole pump with chrome plated pump barrel

Product description

Sucker rod pump is also called insert pump,the main feature is this type pump has two working barrels,the upper is the outer working barrel which are equipment with vertebral body seat and clamp spring,put the outer working barrel into tubing with the well first,then connect the inner working barrel which is equipment liner and piston in the lower end of the sucker rod pump, after that put it in the outer barrel, and fixed by a circlip.

Feature

1. Rod pump can be pulled out from the well directly.

2. Reduce the cost of pumping test.

3.Well inspection and workover is convenient.

4. Suitable for deeper well.

Technical Specifications

Type	Major technical data
Type	Diameter(mm)	Barrel Length (m)	Stroke Range (m)	Length of Extension Pub Joint(m)	Thread for Tubing(in)	Connecting sucker rod
Rod pumps	31.8	2.1 2.4 2.7 3.0 3.3 3.6 3.9 4.2 4.5 4.8 5.7 6.0 6.6 7.3 9.1	1.5-6	0.3 0.6 0.9	2 3/8	CYG16
	38.1				2 7/8	CYG19
	44.45				2 7/8	CYG19
Tubing pump	31.8		1.5-7.8	0.3 0.6 0.9	2 3/8	CYG16
	38.1				2 7/8	CYG16
	44.45				2 7/8	CYG16
	57.15				2 7/8	CYG19
	69.85				2 7/8 3 1/2	CYG22
	82.55				3 1/2	CYG25
	95.25				3 1/2	CYG25

Pictures

API 11AX Oilfield Rod Pump Downhole Pump With Chrome Plated Pump Barrel 0
