Product Details
Place of Origin: China
Brand Name: Zhongshi
Certification: API, ISO, QHSE
Model Number: TH(B)M
Payment & Shipping Terms
Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: Standard exported packing
Delivery Time: 10~15 workdays
Payment Terms: L/C, D/P, T/T, Western Union, D/A
Supply Ability: 1000 SETS/MONTH
Model: |
THM |
Type: |
Tubing Pump |
Application: |
Crude Oil Pumping |
Cage Coating: |
Stellite |
Barrel Coating: |
Chrome Plated |
Barrel Material: |
Carbon Steel |
Model: |
THM |
Type: |
Tubing Pump |
Application: |
Crude Oil Pumping |
Cage Coating: |
Stellite |
Barrel Coating: |
Chrome Plated |
Barrel Material: |
Carbon Steel |
THM Well Tubing Pump With Steel Stellite Insert Cages
THM type tubing pump description
Subsurface sucker tubing pump is applied to pumping crude oil from oil well with pumping unit and sucker rod. Through sucker rod,tubing pump is descent to certain depth of oil. When pumping unit drives sucker rod to move up and down, sucker rod drives plunger of subsurface sucker rod pump move up and down in tubing barrel and pump crude to surface.
Pump barrel, plunger and accessories are specially treated which have the advantages of abrasive and corrosion resistance. It is suitable for pumping oil from oil well which contains sand, wax, gas and water.
THM is the mechanical type anchor.
THM Tubing Pump Parts List
| API code | Description for parts | Quantity in one pump |
| B13 | Barrel, Heavy wall | 1 |
| C11 | Cage, Top open | 1 |
| C13 | Cage, Closed plunger | 1 |
| C16 | Cage, Standing | 1 |
| C34 | Coupling, Tubing | 2 |
| C35 | Coupling, Barrel | 2 |
| N13 | Nipple, Seating, Cup type | 1 |
| N21 | Nipple, Extension, Upper | 1 |
| N22 | Nipple, Extension, Lower | 1 |
| P21 | Plunger, One piece | 1 |
| P31 | Puller, Standing valve | 1 |
| S22-20-1 | mandrel | |
| 1 | ||
| S22-20-2 | brass sleeve | |
| 1 | ||
| S22-20-3 | lock | 1 |
| V11 | Traveling and standing valve | 3 |
Delivery photos
