Product Details
Place of Origin: China
Brand Name: Zhongshi
Certification: API, ISO, QHSE
Model Number: RHAC
Payment & Shipping Terms
Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: Standard exported packing
Delivery Time: 10~15 workdays
Payment Terms: L/C, D/P, T/T, Western Union, D/A
Supply Ability: 1000 SETS/MONTH
Pump Material: |
Carbon Steel In Usual |
Application: |
Oil Production Pump |
Pump Structure: |
Inserted |
Plunger End: |
Pin End |
Plunger Type 1: |
Plain Surface |
Plunger Type 2: |
With Sand Slotting |
Valve Ball & Seat: |
Double Valve |
Fittings Material: |
Carbon Steel Or Low Alloy Steel |
Pump Material: |
Carbon Steel In Usual |
Application: |
Oil Production Pump |
Pump Structure: |
Inserted |
Plunger End: |
Pin End |
Plunger Type 1: |
Plain Surface |
Plunger Type 2: |
With Sand Slotting |
Valve Ball & Seat: |
Double Valve |
Fittings Material: |
Carbon Steel Or Low Alloy Steel |
Carbon Steel Oil Production Downhole Rod Inserted Pump
Oil production downhole rod inserted pump description:
Based on the conventional subsurface pumps, a series of special purpose pumps were developed, which can apply to different well conditions.
Rod pump is equipped with a support joint, support joint connected on the tubing string, and it is together with the tubing string down to the bottom. Plunger assembly is connected on the rod string and together with the whole pump down to support joint position, pump is fixed within the support joint by external force, plunger assembly is together with the sucker rod string up and down reciprocating movement to achieve pumping work.
Rod pump should be installed inside the tubing with the sucker rod. It is not necessary to pull the tubing out of the well when checking the pump, which can make the operation easier and quicker.
RHBC rod inserted pump Technical specifications:
| RHBC model | Pump OD (in) | Barrel length (ft) | Plunger length (ft) | Stroke length (ft) | Extension length (ft) | Tubing size EUE(in) | Sucker rod size |
| 15-106RHBC | Ø26.99 | 2.1-10.4 | 0.3-8.0 | 1.2-9.0 | 0.3-0.9 | 1.9” |
CYJ16 CYJ19 |
| 20-125RHBC | Ø31.75 | 2-3/8” | |||||
| 25-150RHBC | Ø38.10 | 2-7/8” | |||||
| 25-175RHBC | Ø44.45 | 2-7/8” | |||||
| 30-225RHBC | Ø57.15 | 3-1/2” |
Packing photo for inserted pump:
