Product Details:
Payment & Shipping Terms:
|
| Product:: | Polished Rod | Length: | 25ft |
|---|---|---|---|
| Packaging Details: | As Required | Sucker Rod Size: | 5/8", 3/4", 7/8", 1", 1-1/8", 1-1/4", 1-1/2" |
| Key Words: | Rony Rod Polished Rod | Standard: | API 11B |
| Material: | AISI 4140 | ||
| High Light: | high strength steel rod,1 inch diameter steel rod |
||
All Sizes 3/4"- 1 1/4" API 11B Oilfield Drilling Tool Hollow Sucker Rod Polished Rod Steel Pony Rod
Products Descriptions:
API 11B 7/8 1 1/4 inch Sucker Rod PCP Rod Polished Rod for Oil and Gas Extraction Grade D H HL
Polished Rod with an optimal surface finishing to ensure an appropriate sealing in the stuffing box.
One end diameter enlarged polished rod and high-strength, long stroke, corrosion resistant polished rod are available. All the polished rods are made of quality alloy steel and machined by using the advanced machining technology with high strength, smooth surface and long service life. All types of the polished rods are API and ISO9002 certified. The tensile strength exceeds 1, 000 MPa (145, 000psi).
Fearures:
1. Size:5/8”, 3/4” 7/8”, 1”, 1 1/8”, and 1 1/4”
2. Grade C, D, K, HY, HL
3. AISI 4142, AISI4XX, Chrome Ally (20CrMoA or 30CrMoA), ASTM4118
4. polished, varnish or spray metal
5. Packed in boxes made by wood rack
6. Heavy duty in moderate corrosive condition with inhibitor & suitable for H2S
A sucker rod is a steel rod, threaded at both ends, used in the oil industry to join together the surface and downhole components of a reciprocating piston pump installed in an oil well. The pump jack is the visible above-ground drive for the well pump, and is connected to the downhole pump at the bottom of the well by a series of interconnected sucker rods.
Specifications of Polished Rods:
| Nominal Size |
Body OD (in) |
Thread Nominal (in) |
Shoulder Face OD (in) | Wrench flat width (in) |
Length (ft) |
| 5/8” | 5/8” | 1 5/16” | 1-1/4” | 7/8” |
25 26.2 30 |
| 3/4” | 3/4” | 1 1/16” | 1-1/2” | 1” | |
| 7/8” | 7/8” | 13/16” | 1-5/8” | 1” | |
| 1” | 1” | 1 3/8” | 2” | 1-5/16” |
