Alloy Steel Seamless Casing Pipe For Oilfield Well Drilling Project API 5CT Certified

Product Details

Place of Origin: China

Brand Name: Zhongshi

Certification: API 5CT, ISO, QHSE

Model Number: 4 1/2"-20"

Payment & Shipping Terms

Minimum Order Quantity: 1 metric ton

Price: Negotiable

Packaging Details: Be bundled by steel strap

Payment Terms: T/T, L/C

Get Best Price
Highlight:

seamless steel casing pipes

,

seamless drill pipe

Standard:
API 5CT
Production Class:
PSL1 PSL2 PSL3
Steel Grade:
J55, K55, N80, L80, P110, 13Cr
Structure:
Seamless
Application:
Oil Drilling
Technique:
Hot-rolled
Standard:
API 5CT
Production Class:
PSL1 PSL2 PSL3
Steel Grade:
J55, K55, N80, L80, P110, 13Cr
Structure:
Seamless
Application:
Oil Drilling
Technique:
Hot-rolled
Alloy Steel Seamless Casing Pipe For Oilfield Well Drilling Project API 5CT Certified

API 5CT Certified Alloy Steel Seamless Casing Pipe For Oilfield Well Drilling Project


Oil casing pipe descriptions:

Casing pipe is most often used in underground construction projects to encase or protect utility lines
from being damaged.
Once a well has been drilled, if it is to become a production well, the well must undergo completion.
While drilling a well cuts through the rock formations and allows drilling engineers to reach the reservoir
below, the raw sides of the well cannot support themselves.


Features:


1. Materials: H40, J55, K55, N80-1, N80-Q, L80-1,L80-9Cr, L80-13Cr, P110, Q125 etc
2. Executive standards: API 5CT, GB, ISO11960, GOST
3. Thread connection: NU, EU,IJ
4. Length: R1, R2, R3
5. Testing: NDT etc related rules of API 5CT and 5B
6. Type:seamless pipe




Technical specification:



Product Name Oil casing pipe
Diameter 4 1/2" - 20"
Steel Grade J55/ K55, N80-1, N80Q, L80,C90, T95, P110
Ends PE, STC, LTC, BTC, EU,IEU, , Top, New
Certificate API 5CT





Mechanical properties:



Grade Yield Strength Tensile Strenght Hardness Allowable
Min Max Min Max Max Hardness
Psi Mpa Psi Mpa Psi Mpa HRC BHN Variation
J55 55,000 379 80,000 552 75,000 517 - - -
K55 55,000 379 88,000 552 95,000 655 - - -
N80 80,000 552 110,000 758 100,000 689 - - -
N80-1 80,000 552 95,000 655 95,000 655 23 241 -
C90 90,000 621 105,000 724 100,000 689 25.4 255 3
C95 95,000 655 110,000 758 105,000 724 - - -
T95 95,000 655 110,000 758 105,000 724 25.4 255 3
P110 110,000 758 140,000 965 125,000 862 - - -
