Thin Walled Barrel Rod Insert Pump With Chrome Plated Coating

Thin Walled Barrel Rod Insert Pump With Chrome Plated Coating
Thin Walled Barrel Rod Insert Pump With Chrome Plated Coating

Large Image :  Thin Walled Barrel Rod Insert Pump With Chrome Plated Coating

Product Details:

Place of Origin: China
Brand Name: Zhongshi
Certification: API, ISO, QHSE
Model Number: Sucker rod pump

Payment & Shipping Terms:

Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: Standard exported packing
Delivery Time: 10~15 workdays
Payment Terms: L/C, D/P, T/T, Western Union, D/A
Supply Ability: 1000 SETS/MONTH
Detailed Product Description
Series: RW Model: RWB RWC
Hold-down: Top And Bottom Barrel Type: Thin-walled
API Certificate: 11AX-0061 Warranty: One Year
High Light:

Thin Walled Rod Insert Pump

,

Chrome Plated Rod Insert Pump

,

Thin Walled Sucker Rod Pump

Thin Walled Barrel Rod Insert Pump With Chrome Plated Coating



Thin walled barrel inserted sucker Rod Pump Description



We manufacture all subsurface pumps covered by API Spec 11AX, including all barrel and plunger materials and surface finishes.
This is why our sucker rod pumps can be furnished with the components most suitable for your field of application and pumping operations can easily be extended to corrosive environments.
To achieve maximum performance,API subsurface pumps are machined with extra small clearance between the plunger and the inside wall of the barrel.

Our sucker rod pumps are categorized according to the API 11AX pump designation.
API-RH series, Rod, Stationary Heavy Wall Barrel
API-RW series, Rod, Stationary Thin Wall Barrel

RH series has the top anchor and bottom anchor type, cup hold-down and bottom hold-down

RW series also has the top anchor and bottom anchor type, cup hold-down and bottom hold-down



Technical parameter list:



Model Pump diameter (in) Barrel length (ft) Plunger length (ft) Stroke length (ft) Extension length (ft) Tubing size EUE(in)
20-125RWBM Ø31.75 2.1-10.4 0.3-8.0 1.2-9.0 0.3-0.9 2-3/8”
25-150RWBM Ø38.10 2-7/8”
25-175RWBM Ø44.45 2-7/8”
30-225RWBM Ø57.15 3-1/2”



Features



1. The key component of a sucker-rod lift type of artificial lift system

2. More popular than tubing pump
3. Suitable for low downhole pressure wells, slim holes



Thin Walled Barrel Rod Insert Pump With Chrome Plated Coating 0
