Product Details
Place of Origin: China
Brand Name: Zhongshi
Certification: API, ISO, QHSE
Model Number: RHAC
Payment & Shipping Terms
Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: Standard exported packing
Delivery Time: 10~15 workdays
Payment Terms: L/C, D/P, T/T, Western Union, D/A
Supply Ability: 1000 SETS/MONTH
Size: |
30-250 |
Model: |
RH Or RW |
Size Type: |
Large Size |
Material: |
Carbon Steel |
Application: |
Oil Production |
Barrel Coating: |
Chrome Plated Or Nickel Carbide |
Size: |
30-250 |
Model: |
RH Or RW |
Size Type: |
Large Size |
Material: |
Carbon Steel |
Application: |
Oil Production |
Barrel Coating: |
Chrome Plated Or Nickel Carbide |
30-250 Large Sized Rod Inserted Pump With Spray Metal Plungers
Large sized sucker rod pump description
The Sucker Rod Pumping System (SRP) is considered the most popular artificial lift method worldwide. Its applications cover very low downhole pressure wells, slim holes, multiple completions, high temperature and viscous oil.
To achieve maximum performance,API subsurface pumps are machined with extra small clearance between the plunger and the inside wall of the barrel.
Technical parameters
| RH Models | Pump diameter (in) | Barrel length (ft) | Plunger length (ft) | Stroke length (ft) | Extension length (ft) | Tubing size EUE(in) | Sucker rod size |
| 15-106RHBC | Ø26.99 | 2.1-10.4 | 0.3-8.0 | 1.2-9.0 | 0.3-0.9 | 1.9” |
CYJ16 CYJ19 |
| 20-125RHBC | Ø31.75 | 2-3/8” | |||||
| 25-150RHBC | Ø38.10 | 2-7/8” | |||||
| 25-175RHBC | Ø44.45 | 2-7/8” | |||||
| 30-225RHBC | Ø57.15 | 3-1/2” |
Features:
1. Stable performance, high pumping efficiency.
2. Easy operations Suitable for high temperature, corrosion, sand and less gas well conditions.
3. Insertable into the tubing, API specifications
