Product Details
Place of Origin: China
Brand Name: Zhongshi
Certification: API, ISO, QHSE
Model Number: RHAC
Payment & Shipping Terms
Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: Standard exported packing
Delivery Time: 10~15 workdays
Payment Terms: L/C, D/P, T/T, Western Union, D/A
Supply Ability: 1000 SETS/MONTH
Other Pump Name: |
Subsurface Pump |
Pump Type: |
Oilfield Pump |
Application: |
Oil Production |
Pump Configuration: |
Insert Pump |
Size: |
3/4",1 1/8",1",5/8,25-225 |
API Standard: |
11AX |
Basic Material: |
High Carbon Steel |
Plunger Coating: |
Spray Metal |
Other Pump Name: |
Subsurface Pump |
Pump Type: |
Oilfield Pump |
Application: |
Oil Production |
Pump Configuration: |
Insert Pump |
Size: |
3/4",1 1/8",1",5/8,25-225 |
API Standard: |
11AX |
Basic Material: |
High Carbon Steel |
Plunger Coating: |
Spray Metal |
Subsurface oilfield sucker rod pump insert pump
Subsurface oilfield sucker rod pump insert pump description:
The subsurface sucker rod pumps are manufactured in accordance with API 11AX, and have been API monogrammed and ISO 9001 licensed. Technology was introduced from USA in 1980's. More than 40 models and sizes of sucker rod pumps are available with the diameter ranging from 28 mm to 108 mm. Conventional pump types: rod pump, tubing pump and special purpose pump.
Main pump parts
In the rod - having pump operation, API standard subsurface sucker rod pump is one quite important downhole oil production equipment. which can be divided into tubing pump and rod pump.
The main spare parts of subsurface sucker rod pumps are barrel, plunger and valve.
RH rod insert pump Technical specification table:
| RHBC | Pump OD (in) | Barrel length (ft) | Plunger length (ft) | Stroke length (ft) | Extension length (ft) | Tubing size EUE(in) | Sucker rod |
| 15-106RHBC | Ø26.99 | 2.1-10.4 | 0.3-8.0 | 1.2-9.0 | 0.3-0.9 | 1.9” |
CYJ16 CYJ19 |
| 20-125RHBC | Ø31.75 | 2-3/8” | |||||
| 25-150RHBC | Ø38.10 | 2-7/8” | |||||
| 25-175RHBC | Ø44.45 | 2-7/8” | |||||
| 30-225RHBC | Ø57.15 | 3-1/2” |
Rod insert pump features:
1. High oil pumping efficiency.
2. Tubing pump is heavy barrel wall type, more stronger.
3. Mechanical seating is suitable for deep high temperature oil well.
Rod insert pump packing photo:
