Oilfield Production Sucker Rod Pump With Environmental Protection Energy Saving

Product Details

Place of Origin: China

Brand Name: Zhongshi

Certification: API, ISO, QHSE

Model Number: TH(B)M

Payment & Shipping Terms

Minimum Order Quantity: 1 set

Price: Negotiable

Packaging Details: Standard exported packing

Delivery Time: 10~15 workdays

Payment Terms: L/C, D/P, T/T, Western Union, D/A

Supply Ability: 1000 SETS/MONTH

Get Best Price
High Light:

plunger oil pump

,

deep well pump

Application:
Petroleum Production
Color:
Required
Type:
Tubing Pump
Certificate:
API 11 Ax
Delivery Time::
Depends On Quantity
Material:
Chromium Molybdenum Alloy Steel
Application:
Petroleum Production
Color:
Required
Type:
Tubing Pump
Certificate:
API 11 Ax
Delivery Time::
Depends On Quantity
Material:
Chromium Molybdenum Alloy Steel
Oilfield Production Sucker Rod Pump With Environmental Protection Energy Saving

Oilfield Production Sucker Rod Pump With Environmental Protection Energy Saving



Product description

Tubing Pump is also called pipe type pump,the feature is that assemble the outer cylinder liner,the bush and the suction valve well on the ground,and connect at the bottom of the oil,into the wells,then use the sucker rod pump through tubing to put the piston is provided with a discharge valve into the pump.

Technical Specifications


 Major technical Specification
TypeDiameter(mm)Barrel Length (m)Stroke Range (m)Length of Extension Pub Joint(m)Thread for Tubing(in)
Rod pumps31.8

2.1
2.4
2.7

3.0
3.3
3.6
3.9
4.2
4.5
4.8
5.7
6.0
6.6
7.3
9.1

1.5-60.3
0.6
0.9
2 3/8
 38.1   2 7/8
 44.45   2 7/8
Tubing
pump
31.8 1.5-7.8

0.3
0.6
0.9

2 3/8
 38.1   2 7/8
 44.45   2 7/8
 57.15   2 7/8
 69.85   2 7/8 3 1/2
 82.55   3 1/2
 95.25   3 1/2


Pictures

Oilfield Production Sucker Rod Pump With Environmental Protection Energy Saving 0
Oilfield Production Sucker Rod Pump With Environmental Protection Energy Saving 1
