Heavy Wall Barrel Well Pump Tubing For Oilfield Production With Simple Operation

Product Details

Place of Origin: China

Brand Name: Zhongshi

Certification: API, ISO, QHSE

Model Number: Tubing Pump

Payment & Shipping Terms

Minimum Order Quantity: 1 set

Price: Negotiable

Packaging Details: Standard exported packing

Delivery Time: 10~15 workdays

Payment Terms: L/C, D/A, D/P, T/T, Western Union

Supply Ability: 1000 SETS/MONTH

Get Best Price
Highlight:

plunger oil pump

,

deep well pump

Product Name:
TH(B)M Tubing
Manufacturer:
Puyang Zhongshi Group
Certification:
TH(B)M Tubing
Usage:
Oilfield Production
Barrel Type:
Heavy Wall Barrel
Product Name:
TH(B)M Tubing
Manufacturer:
Puyang Zhongshi Group
Certification:
TH(B)M Tubing
Usage:
Oilfield Production
Barrel Type:
Heavy Wall Barrel
Heavy Wall Barrel Well Pump Tubing For Oilfield Production With Simple Operation

Heavy Wall Barrel Well Pump Tubing For Oilfield Production With Simple Operation



Product description:



The barrel assembly of tubing pump is connected directly fixed on the tubing string, and with the pump down to the bottom. Plunger assembly is connected with rod string and down into the bottom hole pump barrel, moving up and down, so as to realize the production process.
In the process of production, when traveling valve and standing valve have problems , they can be put out of the well through the rod string, plunger and puller, without put the whole pump and tubing string out of the well, reduce the labor intensity of operation, reduce the operation cost.





Technical parameter list:



Specification Pump diameter (in) Barrel length (ft) Plunger length (ft) Stroke length (ft) Extension length (ft) Tubing size EUE(in) Sucker rod size
20/25-106THM Ø26.99 ≦6



0.3-8.0



1.2-9.0



0.6-1.2





2-3/8”



2-7/8”



CYB16



CYB19



CYB25

20/25-125THM Ø31.75 2.1-10.4
20/25-150THM Ø38.10
20-175THM Ø44.45
25-200THM Ø50.80
25-225THM Ø57.15
30-275THM Ø69.85 3-1/2”
40-375THM Ø95.25 4-1/2”
